APL3535
Active
5.5V, 7A Low RDSON Power Load Switch with Current Monitoring
Features
General Description
The APL3535 is a power-distribution switch with some protection functions that can deliver current up to 7A. The device incorporates a 12mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft start ramp-up rate control that can be used in application where the inrush current is concerned. The APL3535 integrates some protection features, including current limit protection, over temperature protection. The current limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 155°C. Other features include an accurate current monitor function. The device is available in lead free QFN2x2-12A package.
Features
- N-CH MOSFET RDS(ON): 12mΩ(typ.)
- Smaller than 1uA Shutdown Current
- Ultra-Low Quiescent Current: Less than 50uA
- Input Voltage Range (VIN): 0.7V ~ 5.5V
- Bias Voltage Range (VCC): 3V ~ 5.5V
- Built in Internal Charge Pump Function for Internal Gate Driver
- Built in ADJ Current Limit Function
- Built in Output Discharge Function
- Built in Adjustable Soft Start Function by SS Pin
- Built in Over-Temperature Protection
- <200ns Short-Circuitry Response Protection
- Built in Enable / Shutdown Control by EN Pin
- Built in Power Good Indication Output
- Built in IMON Function with 6% Accuracy
- Tiny Small QFN2x2-12A Package
General Description
The APL3535 is a power-distribution switch with some protection functions that can deliver current up to 7A. The device incorporates a 12mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft start ramp-up rate control that can be used in application where the inrush current is concerned. The APL3535 integrates some protection features, including current limit protection, over temperature protection. The current limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 155°C. Other features include an accurate current monitor function. The device is available in lead free QFN2x2-12A package.
APL3228
Active
High-Current Overvoltage Protectors With Adjustable OVLO
Features
- Preset internal accurate OVLO threshold: 6.8V
- Overvoltage lockout
General Description
The APL3228 overvoltage protection devices feature a low 50mΩ (typ) RON internal FET and protect low-voltage systems against voltage faults up to +28VDC. An internal clamp also protects the devices from surges up to +100V. When the input voltage exceeds the overvoltage threshold, the internal FET is turned off to prevent damage to the protected downstream components. The overvoltage protection threshold can be adjusted with optional external resistors to any voltage between 4V and 20V. With the OVLO input set below the external OVLO select voltage, the APL3228 automatically choose the accurate internal trip thresholds. The internal overvoltage thresholds (OVLO) are preset to 6.8V. The devices feature an open-drain (ACOK)' output indicating a stable supply between minimum supply voltage and VOVLO. The APL3228 are also protected against over current events by an internal thermal shutdown.
Features
- Wide supply voltage range from 3.8V to 28V
- Low ON resistance: 50mΩ (typ) at a supplyvoltage of 5V
- Flexible overvoltage-protection trip level
- Preset internal accurate OVLO threshold: 6.8V
- Low quiescent current 70µA
- Internal 8ms startup debounce
- Protection circuitry:
- Overvoltage lockout
- Low Capacitance ESD Protection
- Available in TDFN3x3-10 Packages
- Lead Free Green Devices Available (RoHS Compliant)
General Description
The APL3228 overvoltage protection devices feature a low 50mΩ (typ) RON internal FET and protect low-voltage systems against voltage faults up to +28VDC. An internal clamp also protects the devices from surges up to +100V. When the input voltage exceeds the overvoltage threshold, the internal FET is turned off to prevent damage to the protected downstream components. The overvoltage protection threshold can be adjusted with optional external resistors to any voltage between 4V and 20V. With the OVLO input set below the external OVLO select voltage, the APL3228 automatically choose the accurate internal trip thresholds. The internal overvoltage thresholds (OVLO) are preset to 6.8V. The devices feature an open-drain (ACOK)' output indicating a stable supply between minimum supply voltage and VOVLO. The APL3228 are also protected against over current events by an internal thermal shutdown.
APL3511A
Active
USB Power-Distribution Switches
Features
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 70mΩ (MSOP-8) High Side MOSFET
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 85153
- TUV IEC/EN60950-1 Certified, No. 44 780 16 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3511B
Active
USB Power-Distribution Switches
Features
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 70mΩ (MSOP-8) High Side MOSFET
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 85153
- TUV IEC/EN60950-1 Certified, No. 44 780 16 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3511C
Active
USB Power-Distribution Switches
Features
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 70mΩ (MSOP-8) High Side MOSFET
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 85153
- TUV IEC/EN60950-1 Certified, No. 44 780 16 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3511D
Active
USB Power-Distribution Switches
Features
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 70mΩ (MSOP-8) High Side MOSFET
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 85153
- TUV IEC/EN60950-1 Certified, No. 44 780 16 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3510/1 series of power switches are designed for USB applications. The 70mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3512A
Active
Power-Distribution Switches with Soft Start
Features
APL3512B: Active Low
General Description
The APL3512A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5, TDFN2x2-6 and SOP-8 packages with enable active-high (EN) and active-low (ENB) versions.
Features
- 90mΩ High Side MOSFET
- 2A Continuous Current
- Soft-Start Time Programmable by External Capacitor
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Logic Level Enable Input
APL3512B: Active Low
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3512A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5, TDFN2x2-6 and SOP-8 packages with enable active-high (EN) and active-low (ENB) versions.
APL3512B
Active
Power-Distribution Switches with Soft Start
Features
APL3512B: Active Low
General Description
The APL3512A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5, TDFN2x2-6 and SOP-8 packages with enable active-high (EN) and active-low (ENB) versions.
Features
- 90mΩ High Side MOSFET
- 2A Continuous Current
- Soft-Start Time Programmable by External Capacitor
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Logic Level Enable Input
APL3512B: Active Low
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3512A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5, TDFN2x2-6 and SOP-8 packages with enable active-high (EN) and active-low (ENB) versions.
APL3512C
Active
Power-Distribution Switches With Soft Start
Features
General Description
The APL3512C is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 package.
Features
- 90mΩ High Side MOSFET
- 2A Continuous Current
- Soft-Start Time Programmable by External Capacitor
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Logic Level Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3512C is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 package.
APL3514A
Active
Power-Distribution Switches with Soft Start
Features
APL3514B: Active Low
General Description
The APL3514A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has internal soft start control to minimize inrush current. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 packages with enable active-high (EN) and active-low (ENB) versions.
Features
- 90mΩ High Side MOSFET
- 2A Continuous Current
- Bulit-In 2ms Soft Start Control
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Logic Level Enable Input
APL3514B: Active Low
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3514A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has internal soft start control to minimize inrush current. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 packages with enable active-high (EN) and active-low (ENB) versions.
APL3514B
Active
Power-Distribution Switches with Soft Start
Features
APL3514B: Active Low
General Description
The APL3514A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has internal soft start control to minimize inrush current. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 packages with enable active-high (EN) and active-low (ENB) versions.
Features
- 90mΩ High Side MOSFET
- 2A Continuous Current
- Bulit-In 2ms Soft Start Control
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Logic Level Enable Input
APL3514B: Active Low
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3514A/B is a power-distribution switch with some protection functions that can deliver current up to 2A. The device incorporates a 90mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and has internal soft start control to minimize inrush current. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 packages with enable active-high (EN) and active-low (ENB) versions.
APL3516
Active
Power-Distribution Switches
Features
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
Features
- 40mΩ (3.3V Input) High Side MOSFET
- Current-Limit and Short Circuit Protections
- Over-Temperature Protection
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Disabled
- Deglitched Fault Indication Output
- Internal Soft-Start Control
- Output Discharge when Disabled
- Logic Level Enable Input
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
APL3516A
Active
Power-Distribution Switches
Features
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
Features
- 40mΩ (3.3V Input) High Side MOSFET
- Current-Limit and Short Circuit Protections
- Over-Temperature Protection
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Disabled
- Deglitched Fault Indication Output
- Internal Soft-Start Control
- Output Discharge when Disabled
- Logic Level Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 87387
- TUV IEC/EN60950-1 Certified, No. 44 780 15 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
APL3516B
Active
Power-Distribution Switches
Features
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
Features
- 40mΩ (3.3V Input) High Side MOSFET
- Current-Limit and Short Circuit Protections
- Over-Temperature Protection
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Disabled
- Deglitched Fault Indication Output
- Internal Soft-Start Control
- Output Discharge when Disabled
- Logic Level Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 87387
- TUV IEC/EN60950-1 Certified, No. 44 780 15 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
APL3516C
Active
Power-Distribution Switches
Features
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
Features
- 40mΩ (3.3V Input) High Side MOSFET
- Current-Limit and Short Circuit Protections
- Over-Temperature Protection
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Disabled
- Deglitched Fault Indication Output
- Internal Soft-Start Control
- Output Discharge when Disabled
- Logic Level Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 87387
- TUV IEC/EN60950-1 Certified, No. 44 780 15 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
APL3516D
Active
Power-Distribution Switches
Features
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
Features
- 40mΩ (3.3V Input) High Side MOSFET
- Current-Limit and Short Circuit Protections
- Over-Temperature Protection
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Disabled
- Deglitched Fault Indication Output
- Internal Soft-Start Control
- Output Discharge when Disabled
- Logic Level Enable Input
- UL Approved-File No. E328191
- Nemko IEC/EN60950-1 CB Scheme Certified, No. 87387
- TUV IEC/EN60950-1 Certified, No. 44 780 15 406748-014
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3516A/B/C/D series are 40mΩ (3.3V input) high side load switches with an EN logic input and an OCB fault indication output. The protection features include current-limit protection, short circuit protection, and over-temperature protection. The device limits the output current at current-limit threshold level. When VOUT drops below 1.5V, the devices limit the current to a lower and safe level. The OTP limits the junction temperature below 140oC in case of short circuit or over load conditions.
APL3517
Active
Compact, Small Package 100mA Power-Distribution Switches
Features
General Description
The APL3517/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
Features
- High Side N-MOSFET with Internal Charge Pump
- 0.1A Continuous Current
- Built-in Soft-Start
- Wide Supply Voltage Range
- Current-Limit Protection
- Input Voltage Under Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Output OVP Protection
- Reverse Current-Limit Protection
- Output Discharge
- Over-Temperature Protection
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3517/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
APL3517A
Active
Compact, Small Package 100mA Power-Distribution Switches
Features
General Description
The APL3517/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
Features
- High Side N-MOSFET with Internal Charge Pump
- 0.1A Continuous Current
- Built-in Soft-Start
- Wide Supply Voltage Range
- Current-Limit Protection
- Input Voltage Under Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Output OVP Protection
- Reverse Current-Limit Protection
- Output Discharge
- Over-Temperature Protection
- UL Approved-File No.E328191
- Nemko IEC 60950-1 : 2005 (2nd Edition); Am 1 : 2009 CB; EN60950-1 : 2006; A11 : 2009; A1 : 2010 Scheme Certified, No 65711
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3517/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
APL3517B
Active
Compact, Small Package 100mA Power-Distribution Switches
Features
General Description
The APL3517/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
Features
- High Side N-MOSFET with Internal Charge Pump
- 0.1A Continuous Current
- Built-in Soft-Start
- Wide Supply Voltage Range
- Current-Limit Protection
- Input Voltage Under Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Output OVP Protection
- Reverse Current-Limit Protection
- Output Discharge
- Over-Temperature Protection
- UL Approved-File No.E328191
- Nemko IEC 60950-1 : 2005 (2nd Edition); Am 1 : 2009 CB; EN60950-1 : 2006; A11 : 2009; A1 : 2010 Scheme Certified, No 65711
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3517/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
APL3517G
Active
Compact, Small Package 100mA Power-Distribution Switches
Features
General Description
The APL3517G is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage
exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 package.
Features
- High Side N-MOSFET with Internal Charge Pump
- 0.1A Continuous Current
- Built-in Soft-Start
- Wide Supply Voltage Range
- Current-Limit Protection
- Input Voltage Under Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Output OVP Protection
- Reverse Current-Limit Protection
- Output Discharge
- Over-Temperature Protection
- UL Approved-File No.E328191
- Nemko IEC 60950-1 : 2005 (2nd Edition); Am 1 : 2009 CB; EN60950-1 : 2006; A11 : 2009; A1 : 2010 Scheme Certified, No 65711
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3517G is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 0.1A. The device incorporates a 250mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage
exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 package.
APL3522A/B
Active
Power-Distribution Switches with Discharge
Features
APL3522B: Active Low
General Description
The APL3522A/B is a power-distribution switch with some protection functions that can deliver current up to 2.5A. The device incorporates a 60mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. It can be programmable VOUT discharge function by DIS pin. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 packages with enable active-high (EN) and active-low (ENB) versions.
Features
- 60mΩ High Side MOSFET
- 2.5A Continuous Current
- Programmable VOUT Discharge Function by DIS Pin
- Wide Supply Voltage Range: 2.7V to 5.5V
- Current-Limit and Short-Circuit Protections
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Logic Level Enable Input
APL3522B: Active Low
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3522A/B is a power-distribution switch with some protection functions that can deliver current up to 2.5A. The device incorporates a 60mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. It can be programmable VOUT discharge function by DIS pin. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1.5V the devices limit the current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-5 packages with enable active-high (EN) and active-low (ENB) versions.
APL3523
Active
Ultra-Low On-Resistance, 6A Dual Load Switch with Soft Start
Features
General Description
The APL3523 is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
Features
- 16mΩ (Typical) On-resistance per Channel
- 6A Continuous Current
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VBIAS): 3V to 5.5V
- Output Discharge when Switch Disabled
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3523 is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
APL3523A
Active
Ultra-Low On-Resistance, 6A Dual Load Switch with Soft Start
Features
General Description
The APL3523A is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14 packages.
Features
- 16mΩ (Typical) On-resistance per Channel
- 6A Continuous Current
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VBIAS): 3V to 5.5V
- Output Discharge when Switch Disabled
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3523A is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14 packages.
APL3526
Active
Ultra-Low On-Resistance, 6A Load Switch with Soft Start
Features
General Description
The APL3526/B is an ultra-low on-resistance, power-distribution switch with external soft start control. It integrates a N-channel MOSFET that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 packages.
Features
- 15mΩ (Typical) On-resistance
- 6A Continuous Current
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VBIAS): 3V to 5.5V
- Output Discharge when Switch Disabled
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3526/B is an ultra-low on-resistance, power-distribution switch with external soft start control. It integrates a N-channel MOSFET that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 packages.
APL3526B
Active
Ultra-Low On-Resistance, 6A Load Switch with Soft Start
Features
General Description
The APL3526/B is an ultra-low on-resistance, power-distribution switch with external soft start control. It integrates a N-channel MOSFET that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 packages.
Features
- 15mΩ (Typical) On-resistance
- 6A Continuous Current
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VBIAS): 3V to 5.5V
- Output Discharge when Switch Disabled
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3526/B is an ultra-low on-resistance, power-distribution switch with external soft start control. It integrates a N-channel MOSFET that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 packages.
APL3527
Active
Ultra-Low On-Resistance, Power Load Switch with Soft Start
Features
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3527A/D
Active
Ultra-Low On-Resistance, Power Load Switch with Soft Start
Features
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3527B/E
Active
Ultra-Low On-Resistance, Power Load Switch with Soft Start
Features
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3527C/F
Active
Ultra-Low On-Resistance, Power Load Switch with Soft Start
Features
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3527G/H
Active
Ultra-Low On-Resistance, Power Load Switch with Soft Start
Features
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527 is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3527SA/D
Active
Ultra-Low On-Resistance, Power Load Switch With Soft Start
Features
General Description
The APL3527S is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527S is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3527SB/E
Active
Ultra-Low On-Resistance, Power Load Switch With Soft Start
Features
General Description
The APL3527S is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527S is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3527SG/H
Active
Ultra-Low On-Resistance, Power Load Switch With Soft Start
Features
General Description
The APL3527S is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
Features
- Ultra-Low On-Resistance: 15mΩ (typical)
- Low Quiescent Current: 20µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to VDD+0.3
- Supply Voltage Range (VDD): 3V to 5.5V
- Current Limit Protection
- Enable Input
- Output Discharge when Switch Disabled
- Over-Temperature Protection
- Tiny small WLCSP1.16x0.76-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3527S is an ultra-low on-resistance, power-distribution switch with external soft start control. The device integrates some protection features, including current-limit protection and over-temperature protection. The current-limit protection can protect down stream devices from catastrophic failure by limiting the output current at current limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 30oC. The device is available in lead free WLCSP1.16x0.76-6 package.
APL3528
Active
Ultra-Low On-Resistance, 6A Dual Load Switch With Soft Start
Features
General Description
The APL3528 is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
Features
- 20mΩ (Typical) On-resistance per Channel
- 6A Continuous Current
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VBIAS): 3V to 5.5V
- Output Discharge when Switch Disabled
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3528 is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
APL3529A
Active
Ultra-Low On-Resistance, Power Load Switch With Soft Start
Features
General Description
The APL3529A/B is an ultra-low On-resistance, power-distribution switch with external soft start control. The APL3529A/B can be enabled by other power systems. Pulling and holding the EN voltage below 0.4V or ENB above 0.8V will shuts off the output. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 package.
Features
- 7.8mΩ (Typical) On-resistance
- Low Quiescent Current: 30µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VDD): 3V to 5.5V
- Enable Control Function
- Output Discharge when Switch Disabled
- Over-Temperature Protection with Hysteresis
- Tiny small TDFN2x2-8 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3529A/B is an ultra-low On-resistance, power-distribution switch with external soft start control. The APL3529A/B can be enabled by other power systems. Pulling and holding the EN voltage below 0.4V or ENB above 0.8V will shuts off the output. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 package.
APL3529B
Active
Ultra-Low On-Resistance, Power Load Switch With Soft Start
Features
General Description
The APL3529A/B is an ultra-low On-resistance, power-distribution switch with external soft start control. The APL3529A/B can be enabled by other power systems. Pulling and holding the EN voltage below 0.4V or ENB above 0.8V will shuts off the output. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 package.
Features
- 7.8mΩ (Typical) On-resistance
- Low Quiescent Current: 30µA (max)
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VDD): 3V to 5.5V
- Enable Control Function
- Output Discharge when Switch Disabled
- Over-Temperature Protection with Hysteresis
- Tiny small TDFN2x2-8 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3529A/B is an ultra-low On-resistance, power-distribution switch with external soft start control. The APL3529A/B can be enabled by other power systems. Pulling and holding the EN voltage below 0.4V or ENB above 0.8V will shuts off the output. The device integrates over-temperature protection. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x2-8 package.
APL3531
Active
Power-Distribution Switches
Features
General Description
The APL3531 is a power-distribution switch with some protection functions that can deliver current up to 1A. The device incorporates a 100mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SC-70-6 packages.
Features
- 100mΩ High Side MOSFET
- 1A Continuous Current
- Wide Supply Voltage Range: 1.5V to 5.5V
- Current-Limit and Short-Circuit Protections
- Under-Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Logic Level Enable Input
- UL Approved-Fild No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3531 is a power-distribution switch with some protection functions that can deliver current up to 1A. The device incorporates a 100mΩ N-channel MOSFET power switch that is controlled by an enable logic pin and dedicated to soft-start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SC-70-6 packages.
APL3533
Active
Ultra-Low On-Resistance, 6A Dual Load Switch with Soft Start
Features
General Description
The APL3533 is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
Features
- 16mΩ (Typical) On-resistance per Channel
- 6A Continuous Current
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VBIAS): 3V to 5.5V
- Output Discharge when Switch Disabled
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3533 is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
APL3533A
Active
Ultra-Low On-Resistance, 6A Dual Load Switch With Soft Start
Features
General Description
The APL3533A is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
Features
- 16mΩ (Typical) On-resistance per Channel
- 6A Continuous Current
- Soft Start Time Programmable by External Capacitor
- Wide Input Voltage Range (VIN): 0.8V to 5.5V
- Supply Voltage Range (VBIAS): 3V to 5.5V
- Output Discharge when Switch Disabled
- Reverse Current Blocking when Switch Disabled
- Over-Temperature Protection
- Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3533A is an ultra-low on-resistance, dual power-distribution switch with external soft start control. It integrates two N-channel MOSFETs that can deliver 6A continuous load current each. The device integrates over-temperature protection. The over temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 160oC and will automatically turns on the power switch when the temperature drops by 40oC. The device is available in lead free TDFN2x3-14A packages.
APL3534
Active
Compact, Small Package 1A Power-Distribution Switches
Features
General Description
The APL3534/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 1A. The device incorporates a 110mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
Features
- High Side N-MOSFET with Internal Charge Pump
- 1A Continuous Current
- Built-in Soft-Start
- Wide Supply Voltage Range
- Current-Limit and Short-Circuit Protections
- Input Voltage Under Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Output OVP Protection
- Reverse Current-Limit Protection
- Output Discharge
- Over-Temperature Protection
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3534/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 1A. The device incorporates a 110mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
APL3534A
Active
Compact, Small Package 1A Power-Distribution Switches
Features
General Description
The APL3534/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 1A. The device incorporates a 110mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
Features
- High Side N-MOSFET with Internal Charge Pump
- 1A Continuous Current
- Built-in Soft-Start
- Wide Supply Voltage Range
- Current-Limit and Short-Circuit Protections
- Input Voltage Under Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Output OVP Protection
- Reverse Current-Limit Protection
- Output Discharge
- Over-Temperature Protection
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3534/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 1A. The device incorporates a 110mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
APL3534B
Active
Compact, Small Package 1A Power-Distribution Switches
Features
General Description
The APL3534/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 1A. The device incorporates a 110mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
Features
- High Side N-MOSFET with Internal Charge Pump
- 1A Continuous Current
- Built-in Soft-Start
- Wide Supply Voltage Range
- Current-Limit and Short-Circuit Protections
- Input Voltage Under Voltage Lockout Protection
- Reverse Current Blocking when Switch Disabled
- Output OVP Protection
- Reverse Current-Limit Protection
- Output Discharge
- Over-Temperature Protection
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3534/A/B is a power-distribution switch with current-limiting function and output OVP protections that can deliver current up to 1A. The device incorporates a 110mΩ N-channel MOSFET power switch. The device integrates some protection features, including current-limit protection, output over-voltage protection, over-temperature protection and UVLO. The current-limit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. The output over-voltage protection can prevent current flowing from VOUT to VIN when an abnormally high voltage exists in VOUT. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 140oC and will automatically turns on the power switch when the temperature drops by 20oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The device is available in lead free SOT-23-3 and SOT-23-5 packages.
APL3537
Active
Ultra-Low On-Resistance, Power Load Switch With Soft Start
Features
- RDS(ON)=12mΩ at VIN=3.6V
- RDS(ON)=12.3mΩ at VIN=2.5V
- RDS(ON)=12.5mΩ at VIN=1.8V
- RDS(ON)=17.5mΩ at VIN=1V
General Description
The APL3537 is an ultra-low on-resistance, power-distribution switch with internal soft start control. The device is an N-channel MOSFET which needs only one input voltage from 0.95V to 5.5V. Built in internal charge pump function biases the N-MOS switch to achieve a minimum switch on-resistance. The APL3537 can be enabled by other power system. Pulling and holding the EN pin below 0.4V shuts off the output. The device is available in lead free WLCSP 0.9x1.4-6 package.
Features
- Ultra-Low On-Resistance:
- RDS(ON)=12mΩ at VIN=3.6V
- RDS(ON)=12.3mΩ at VIN=2.5V
- RDS(ON)=12.5mΩ at VIN=1.8V
- RDS(ON)=17.5mΩ at VIN=1V
- Ultra-Low Quiescent Current: VIN=1V Condition, 10µA (Max.)
- 3A Maximum Continuous Output Current
- Supply Voltage Range from 0.95V to 5.5V
- Built in Internal Charge Pump Function for Internal Gate Driver
- Built in Internal Soft-Start Function: VIN=3.6V Condition, A: 96µs, B: 800µs (Typ.)
- Built in Enable/Shutdown Control
- Built in Turn On Time: VIN=3.6V Condition, A: 111µs, B: 860µs (Typ.)
- Output Discharge when Switch Disabled
- Built in Reverse Current Block Function
- Tiny small WLCSP 0.9x1.4-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3537 is an ultra-low on-resistance, power-distribution switch with internal soft start control. The device is an N-channel MOSFET which needs only one input voltage from 0.95V to 5.5V. Built in internal charge pump function biases the N-MOS switch to achieve a minimum switch on-resistance. The APL3537 can be enabled by other power system. Pulling and holding the EN pin below 0.4V shuts off the output. The device is available in lead free WLCSP 0.9x1.4-6 package.
APL3537C
Active
Ultra-Low On-Resistance, Power Load Switch with Soft Start
Features
- RDS(ON)=12mΩ at VIN=3.6V
- RDS(ON)=12.3mΩ at VIN=2.5V
- RDS(ON)=12.5mΩ at VIN=1.8V
- RDS(ON)=17.5mΩ at VIN=1V
General Description
The APL3537C is an ultra-low on-resistance, power-distribution switch with internal soft start control. The device is a N-channel MOSFET which needs only one input voltage from 0.95V to 5.5V. Built in internal charge pump function biases the N-MOS switch to achieve a minimum switch on-resistance. The APL3537C can be enabled by other power system. Pulling and holding the EN pin below 0.4V shuts off the output. The device is available in lead free WLCSP 0.9x1.4-6 package.
Features
- Ultra-Low On-Resistance:
- RDS(ON)=12mΩ at VIN=3.6V
- RDS(ON)=12.3mΩ at VIN=2.5V
- RDS(ON)=12.5mΩ at VIN=1.8V
- RDS(ON)=17.5mΩ at VIN=1V
- Ultra-Low Quiescent Current: VIN=1V Condition, 10µA (Max.)
- 3A Maximum Continuous Output Current
- Supply Voltage Range from 0.95V to 5.5V
- Built in Internal Charge Pump Function for Internal Gate Driver
- Built in Internal Soft-Start Function: VIN=3.6V Condition, 800µs (Typ.)
- Built in Enable/Shutdown Control
- Built in Turn On Time: VIN=3.6V Condition, 860µs (Typ.)
- Built in Reverse Current Block Function
- Tiny small WLCSP 0.9x1.4-6 Package
- Lead Free and Green Devices Available (RoHS Compliant)
General Description
The APL3537C is an ultra-low on-resistance, power-distribution switch with internal soft start control. The device is a N-channel MOSFET which needs only one input voltage from 0.95V to 5.5V. Built in internal charge pump function biases the N-MOS switch to achieve a minimum switch on-resistance. The APL3537C can be enabled by other power system. Pulling and holding the EN pin below 0.4V shuts off the output. The device is available in lead free WLCSP 0.9x1.4-6 package.
APL3547A
Active
Power-Distribution Switches with Soft Start
Features
General Description
The APL3547A is a power-distribution switch with some protection functions. The device incorporates a N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1V, the devices limit the output current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 50oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The current limit in APL3547A can be set by connecting resistor from the current limit adjustable pin ISET to ground. The device is available in lead free SOP-8P and TDFN2x2-6 packages.
Features
- 84mΩ High Side MOSFET
- Soft Start Time Programmable by External Capacitor
- Wide Supply Voltage Range: 4.5V to 24V
- Current Limit Protections
- Under Voltage Lockout Protection
- Over-Temperature Protection
- Logic Level Enable Input
- Lead Free and Green Devices Available (RoHS Compliant)
- Current Limit Setting
General Description
The APL3547A is a power-distribution switch with some protection functions. The device incorporates a N-channel MOSFET power switch that is controlled by an enable logic pin and has a SS pin dedicated to soft start ramp-up rate control that can be used in application where the inrush current is concerned. The device integrates some protection features, including current-limit protection, short-circuit protection, over-temperature protection, and UVLO. The current-limit and short-circuit protection can protect down-stream devices from catastrophic failure by limiting the output current at current-limit threshold during over-load or short-circuit events. When VOUT drops below VIN-1V, the devices limit the output current to a lower and safe level. The over-temperature protection function shuts down the N-channel MOSFET power switch when the junction temperature rises beyond 150oC and will automatically turns on the power switch when the temperature drops by 50oC. The UVLO function keeps the power switch in off state until there is a valid input voltage present. The current limit in APL3547A can be set by connecting resistor from the current limit adjustable pin ISET to ground. The device is available in lead free SOP-8P and TDFN2x2-6 packages.
APL3548
Active
6A, 24V High-Side Power Distribution Switch With Softstart
Features
General Description
APL3548 is a high-side power distribution switch, allow for +12V, +19V or +9.5V power-supply rail. The wrong input voltage protection function protects a wrong input of adapter insertion, when input voltage is out of the target input voltage range the IC is off. The APL3548 provides a short-circuit protection during power-up. When a short circuit is present before soft start, the IC will limit the output current at 300mA during dead short condition (VOUT<1V) unless the short circuit has been removed and the output voltage has risen above 1V. After power-up the OCP function prevents the IC from catastrophic failure from over-load and short circuit conditions. If an OC event is detected, the IC immediately shuts down the internal power switch and will initiate a new soft start cycle. The OCP tripping threshold is set by the external resistor on OCSET pin. Other features include an adjustable soft start time and a logic-controlled shutdown mode. The device is available in SOP-8P and TDFN3x3-10 Packages.
Features
- Internal 40mΩ High-Side N-Channel MOSFET
- Under-Voltage Lockout (UVLO)
- Wrong VIN Input Voltage Protection
- Short-Circuit Protection During Power-up (SCP)
- Adjustable OCP Threshold
- Adjustable Softstart Time
- Selectable VIN Monitor Voltage
- Shutdown Function
- Power Good Output
- Available in SOP-8P and TDFN3x3-10 Packages
- Lead Free and Green Devices Available (RoHS Compliant)
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
APL3548 is a high-side power distribution switch, allow for +12V, +19V or +9.5V power-supply rail. The wrong input voltage protection function protects a wrong input of adapter insertion, when input voltage is out of the target input voltage range the IC is off. The APL3548 provides a short-circuit protection during power-up. When a short circuit is present before soft start, the IC will limit the output current at 300mA during dead short condition (VOUT<1V) unless the short circuit has been removed and the output voltage has risen above 1V. After power-up the OCP function prevents the IC from catastrophic failure from over-load and short circuit conditions. If an OC event is detected, the IC immediately shuts down the internal power switch and will initiate a new soft start cycle. The OCP tripping threshold is set by the external resistor on OCSET pin. Other features include an adjustable soft start time and a logic-controlled shutdown mode. The device is available in SOP-8P and TDFN3x3-10 Packages.
APL3552
Active
Adjustable Current Limit Power Distribution Switches
Features
General Description
The APL3552 series of power switches integrate a 62mΩ N-channel MOSFET power switch, an enable input pin, a fault flag and some protection functions into a single package. The protection features include adjustable current limit, reverse current protection, and over temperature protection. APL3552 offer an adjustable current-limit threshold between 150mA and 2.8A (typ.) via an external resistor. The reverse current protection disable the power switch when the output voltage is driven higher than the input to protect devices on the input side of the switch. The OCB output asserts low during over current and reverse current conditions. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions.
Features
- 62mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Adjustable Current Limit Protection
- Fast Over Current Response: 2us (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Reverse Input-Output Voltage Protection: 25mV (typ.)
- Enable Input
- Built-in Soft-Start
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
The APL3552 series of power switches integrate a 62mΩ N-channel MOSFET power switch, an enable input pin, a fault flag and some protection functions into a single package. The protection features include adjustable current limit, reverse current protection, and over temperature protection. APL3552 offer an adjustable current-limit threshold between 150mA and 2.8A (typ.) via an external resistor. The reverse current protection disable the power switch when the output voltage is driven higher than the input to protect devices on the input side of the switch. The OCB output asserts low during over current and reverse current conditions. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions.
APL3553
Active
USB Power-Distribution Switches
Features
General Description
The APL3553 series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 62mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Fix Current Limit Protection
- Fast Over Current Response: 2us (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- Built-in Soft-Start
- Reverse Input-Output Voltage Protection: 25mV (typ.)
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
The APL3553 series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3553E/F/G/H
Active
USB Power-Distribution Switches
Features
General Description
The APL3553E/F/G/H series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 62mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Fix Current Limit Protection
- Fast Over Current Response: 2us (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- Built-in Soft-Start
- Reverse Input-Output Voltage Protection: 25mV (typ.)
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
The APL3553E/F/G/H series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3553I/J
Active
USB Power-Distribution Switches
Features
General Description
The APL3553I/J series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 62mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Fix Current Limit Protection
- Fast Over Current Response: 2us (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- Built-in Soft-Start
- Reverse Input-Output Voltage Protection: 25mV (typ.)
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
The APL3553I/J series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3553K/L
Active
USB Power-Distribution Switches
Features
General Description
The APL3553K/L series of power switches are designed for USB applications. The 75mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB (FLAG/FAULT) output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 75mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Fix Current Limit Protection
- Fast Over Current Response: 2us (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- Built-in Soft-Start
- Reverse Input-Output Voltage Protection: 25mV (typ.)
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
The APL3553K/L series of power switches are designed for USB applications. The 75mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB (FLAG/FAULT) output to indicate the fault condition and an enable input to enable or disable the device.
APL3553M/N
Active
USB Power-Distribution Switches
Features
General Description
The APL3553M/N series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 62mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Fix Current Limit Protection
- Fast Over Current Response: 2us (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- Built-in Soft-Start
- Reverse Input-Output Voltage Protection: 25mV (typ.)
General Description
The APL3553M/N series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3556
Active
Adjustable Current Limit Power Distribution Switches
Features
General Description
The APL3556 series of power switches integrate a 50mΩ N-channel MOSFET power switch, an enable input pin, a fault flag and some protection functions into a single package. The protection features include adjustable/fix current limit, reverse current protection, and over-temperature protection. APL3556 offer an adjustable current-limit threshold between 62mA and 6A (typ.) via an external resistor. The reverse current protection disable the power switch when the output voltage is driven higher than the input to protect devices on the input side of the switch. The FAULT output asserts low during over current and reverse current conditions. The over-temperature protection limits the junction temperature below 150oC in case of short circuit or over load conditions.
Features
- 50mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.9V to 5.5V
- Adjustable Current Limit Protection
- Fast Over Current Response: 2µs (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Reverse Input-Output Voltage Protection: 25mV (typ.)
- Enable Input
- Built-in Soft-Start
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
The APL3556 series of power switches integrate a 50mΩ N-channel MOSFET power switch, an enable input pin, a fault flag and some protection functions into a single package. The protection features include adjustable/fix current limit, reverse current protection, and over-temperature protection. APL3556 offer an adjustable current-limit threshold between 62mA and 6A (typ.) via an external resistor. The reverse current protection disable the power switch when the output voltage is driven higher than the input to protect devices on the input side of the switch. The FAULT output asserts low during over current and reverse current conditions. The over-temperature protection limits the junction temperature below 150oC in case of short circuit or over load conditions.
APL3555
Active
USB Power-Distribution Switches
Features
General Description
The APL3555 series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
Features
- 62mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Fix Current Limit Protection
- Fast Over Current Response: 2us (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Enable Input
- Built-in Soft-Start
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified
- TUV IEC/EN62368-1 Certified
General Description
The APL3555 series of power switches are designed for USB applications. The 62mΩ N-channel MOSFET power switch satisfies the voltage drop requirements of USB specification. The protection features include current-limit protection, short-circuit protection, and over-temperature protection. The device limits the output current at current limit threshold level. When VOUT drops below VIN-1V, the devices limit the current to a lower and safe level. The over-temperature protection limits the junction temperature below 140oC in case of short circuit or over load conditions. Other features include a deglitched OCB output to indicate the fault condition and an enable input to enable or disable the device.
APL3556E/F
Active
Current Limit Power Distribution Switches
Features
General Description
The APL3556EF series of power switches integrate a 50mΩ N-channel MOSFET power switch, an enable input pin, a fault flag and some protection functions into a single package. The protection features include adjustable/fix current limit, reverse current protection, and over temperature protection. APL3556EF offer an adjustable current-limit threshold between 3.6A (typ.) via an external resistor. The reverse current protection disable the power switch when the output voltage is driven higher than the input to protect devices on the input side of the switch. The FAULT output asserts low during over current and reverse current conditions. The over-temperature protection limits the junction temperature below 150oC in case of short circuit or over load conditions.
Features
- 50mΩ Power Switch On Resistance
- Wide Supply Voltage Range: 2.7V to 5.5V
- Fix Current Limit Protection
- Fast Over Current Response: 2µs (typ.)
- Over-Temperature Protection
- Fault Indication Output
- Reverse Input-Output Voltage Protection: 25mV (typ.)
- Enable Input
- Built-in Soft-Start
- UL Approved-File No. E328191
- UL-CB Scheme IEC/EN62368-1 Certified, No. DK83116-UL
- TUV IEC/EN62368-1 Certified, No. 44 780 19 406748-003
General Description
The APL3556EF series of power switches integrate a 50mΩ N-channel MOSFET power switch, an enable input pin, a fault flag and some protection functions into a single package. The protection features include adjustable/fix current limit, reverse current protection, and over temperature protection. APL3556EF offer an adjustable current-limit threshold between 3.6A (typ.) via an external resistor. The reverse current protection disable the power switch when the output voltage is driven higher than the input to protect devices on the input side of the switch. The FAULT output asserts low during over current and reverse current conditions. The over-temperature protection limits the junction temperature below 150oC in case of short circuit or over load conditions.
APL3576A
Active
USB Power-Distribution Switches
Features
- HBM with over 2kV
- CDM with over 500V at VIN pin
General Description
The APL3576A is designed for desktop adapter applications. The low on resistance N-channel MOSFET power switch can satisfy the voltage drop requirements of USB specification. Protection features include current-limit protection, short-circuit protection, over-temperature protection, wrong VIN input voltage protection, surge protection, and reverse current blocking. Other features include a deglitched ACOK output to indicate the fault condition and an enable input to enable or disable the device.
Features
- VIN Input Voltage Range: 4.5 to 25V
- 30V Absolute Ratings at VIN Pin
- 15A Output Current Capability
- Adjustable Soft-start Time by SS pin
- Fast Over Current Protection Response Time
- Wrong VIN Input Voltage Protection
- Fault Report on ACOK Pin
- Built-in Surge Protection when Surge Voltage over 27V
- Built-in Thermal Shutdown Protection
- Built-in Enable / Shutdown Control by DPREN Pin
- Integrated Internal Charge Pump
- Built-in Programmable Short Circuit or Over Current Protection Threshold Setting by ALSET pin
- ESD Protection:
- HBM with over 2kV
- CDM with over 500V at VIN pin
- Over-Temperature Protection
- TQFN4x4-24 Package
General Description
The APL3576A is designed for desktop adapter applications. The low on resistance N-channel MOSFET power switch can satisfy the voltage drop requirements of USB specification. Protection features include current-limit protection, short-circuit protection, over-temperature protection, wrong VIN input voltage protection, surge protection, and reverse current blocking. Other features include a deglitched ACOK output to indicate the fault condition and an enable input to enable or disable the device.
APL6003
Active
High-Current Overvoltage Protectors With Adjustable OVLO
Features
- Preset internal accurate OVLO threshold
- Over voltage lockout
General Description
The APL6003 overvoltage protection devices feature a low 15mΩ (max) RON internal FET and protect low-voltage systems against voltage faults up to +25VDC. An internal clamp also protects the devices from surges up to +120V. When the input voltage exceeds the overvoltage threshold, the internal FET is turned off to prevent damage to the protected downstream components. The overvoltage protection threshold can be adjusted with optional external resistors to any voltage between 4V and 24V. With the OVLO input set below the external OVLO select voltage, the APL6003 automatically choose the accurate internal trip thresholds. The internal overvoltage thresholds (OVLO) are preset to 5.95V typical. The devices feature an open-drain (ACOK)' output indicating a stable supply between minimum supply voltage and VOVLO. The APL6003 are also protected against over current events by an internal thermal shutdown.
Features
- Wide supply voltage range from 2.8V to 25V
- IOUT maximum 6A continuous current under TA=25oC
- Low ON resistance: 15mΩ (Max) at a supply voltage of 5V
- Flexible overvoltage-protection trip level
- Preset internal accurate OVLO threshold
- Low quiescent current 100µA
- Internal 0.3ms startup debounce
- Protection circuitry :
- Over voltage lockout
- Low Capacitance ESD Protection
- Available in WLCSP1.8x2.0-20 Packages
- Lead Free Green Devices Available (RoHS Compliant)
General Description
The APL6003 overvoltage protection devices feature a low 15mΩ (max) RON internal FET and protect low-voltage systems against voltage faults up to +25VDC. An internal clamp also protects the devices from surges up to +120V. When the input voltage exceeds the overvoltage threshold, the internal FET is turned off to prevent damage to the protected downstream components. The overvoltage protection threshold can be adjusted with optional external resistors to any voltage between 4V and 24V. With the OVLO input set below the external OVLO select voltage, the APL6003 automatically choose the accurate internal trip thresholds. The internal overvoltage thresholds (OVLO) are preset to 5.95V typical. The devices feature an open-drain (ACOK)' output indicating a stable supply between minimum supply voltage and VOVLO. The APL6003 are also protected against over current events by an internal thermal shutdown.
