首頁 產品資訊
產品搜尋
SEARCH
( 共有118筆產品,符合搜尋條件 )
Part Number Package & Pins Architecture No. of PWM Outputs Vin (V)-min Vin (V)-max Vref (V) Fmax (kHz) R-Top (mΩ) R-Sync (mΩ) Iq (No load) (μA) Drive Iout (A)
ALL
APW7582 WLCSP0.90x0.74-5 COT 1 2.6 5.5 - 3000 - - 11 0.6
APW8712F TQFN4x4-23 COT 1 2.7 28 0.6 100~1000 30 9 25 12
APW9304H TQFN4x4-20D CM 3 3 18 0.6 1800~2400 60
90
90
45
50
50
420 3
2.5
1.5
APW7085 SOP-8 CM 1 4.5 26 0.8 380 100 - 1000 2
APW7089 SOP-8P CM 1 4.5 26 0.8 380 80 - 1000 4
APW7104 SOT-23-5
TSOT-23-5
CM 1 2.7 6 0.6 1500 280 250 25 1
APW7104A SOT-23-5 CM 1 2.7 6 0.6 1500 280 250 - 1
APW7142 SOP-8 CM 1 4.3 14 0.8 500 70 70 500 3
APW7145 SOP-8P CM 1 4.3 14 0.8 500 55 45 500 3
APW7176 TDFN3x3-10 CM 2 2.7 6 0.6 1500 280 250 500 1
APW7176A TDFN3x3-10 CM 2 2.7 6 0.6 1500 280 250 - 1
APW7178 TDFN2x2-6 CM 1 2.7 6 0.6 1500 280 250 25 1
APW7178A TDFN2x2-6 CM 1 2.7 6 0.6 1500 280 250 - 1
APW7179 TDFN3x3-12 CM 2 2.7 6 0.6 1500 280 250 25 1
APW7179A TDFN3x3-12 CM 2 2.7 6 0.6 1500 280 250 - 1
APW7179C TDFN3x3-12 CM 2 3 5.5 0.6 1500 280 250 30 1
APW7255 TQFN3x3-20 CM 3 2.9 5.5 0.6 1500 - - 300 2
APW7301 SOP-8P CM 1 4.5 24 0.925 340 110 110 1900 3
APW7303 SOP-8P CM 1 4.5 24 0.92 340 85 85 1900 3
APW7307 TSOT-23-8A CM 1 4.5 24 0.807 500 100 40 1000 3
APW7304 SOP-8P CM 1 4.5 24 0.8 340 85 85 1900 4
APW7307A TSOT-23-8A CM 1 4.7 16 0.807 500 100 40 1000 3
APW7309 TSOT-23-8A CM 1 4.5 24 0.807 500 115 50 1000 2
APW7313 SOP-8P CM 1 4.5 24 0.925 340 110 110 1900 3
APW7314 TSOT-23-8A CM 1 4.5 24 0.807 500 115 50 500 2
APW7320 TSOT-23-6
TDFN2x2-6
COT 1 4.5 16 0.6 500 80 52 50 3
APW7322/A SOP-8P
TDFN3x3-10
CM 1 2.5 6 0.8 1000 85 75 460 2
APW7323/A SOP-8P
TDFN3x3-10
CM 1 2.5 6 0.8 1000 85 75 460 3.2
APW7325 SOP-8P CM 1 2.5 6 0.6 1000 65 55 460 5
APW7328 TDFN2x2-12 CM 1 2.7 5.5 0.6 1320 70 60 40 3.5
APW7336 TDFN3x3-10 CM 1 4.5 24 0.8 340 110 110 1900 2
APW7340A SOT-23-6 COT 1 4.5 16 0.6 1400 100 70 50 2
APW7341A SOT-23-6 COT 1 4.5 16 0.6 1400 80 52 50 3
APW7400 FC-TSOT-23-6 COT 1 4.5 16 0.765 650 90 56 50 2
APW7408 SOT-23-5 CM 1 2.9 5.5 0.6 1000 113 95 65 1.3
APW7408B SOT-23-5 CM 1 2.9 5.5 0.6 800~2000 65 35 - 1.3
APW7410 DFN1.5x1.5-6 COT 1 2.5 6 0.6 2200 75 50 50 1
APW7415 TSOT-23-8A CM 1 4.5 24 0.791 500 100 40 1000 3
APW7415S TSOT-23-8A CM 1 7 24 0.791 500 100 40 1000 3
APW7435 TQFN4x4-28B CM 2 4.5 18 0.6 500~2000 35
75
20
30
150 3
6
APW7436 TQFN3x3-20A CM 3 4.5 18 0.6 500~2000 120 30
50
160 1.5
2.5
APW7437 TQFN5x5-28 CM 2 4.5 18 0.6 500~2000 35
75
20
30
150 3
6
APW7438A QFN2x3-14 COT 1 2.7 6 Int. 800~2200 20 8 100 7
APW7504R TDFN2x2-6 CM 1 3 5.5 0.2 1500 220 170 3000 1.2
APW7506A SOT-23-5
TSOT-23-5A
CM 1 3 5.5 0.6 1500 260 230 30 1
APW7506C SOT-23-5
TSOT-23-5A
CM 1 3 5.5 0.6 1500 260 230 30 1
APW7514 TSOT-23-8A CM 1 4.5 24 0.807 500 115 50 1000 2
APW7533 TDFN5x5-16 CM 1 4.5 26 0.8 380 22 - 1000 4
APW7564 WLCSP0.8x1.14-6 COT 1 2.7 5.5 0.5~1.13 1500 - - 3 0.3
APW7705A/B/C/D TQFN5x5-36 CM 5 2.7 5.5 - 1500 - - 1000 2.5
APW8712 TQFN4x4-22 COT 1 2.7 28 0.8 100~1000 30 9 700 8
APW8712E TQFN4x4-22 COT 1 2.7 28 0.8 100~1000 30 9 25 8
APW8713 TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 9 750 6
APW8713A TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 9 700 8
APW8713B TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 9 700 8
APW8713C TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 27 7 700 10
APW8713D TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 27 7 700 10
APW8713E TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 9 25 8
APW8713F TQFN4x4-23 COT 1 2.7 28 0.6 450 30 9 17 12
APW8713CA TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 27 7 700 10
APW8713DA TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 27 7 700 10
APW8714D TQFN4x4-22 COT 1 2.7 28 0.6 100~1000 30 12 35 6
APW8714E TQFN4x4-22 COT 1 2.7 28 0.8 100~1000 30 12 25 6
APW8715 TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 12 700 6
APW8715A TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 12 700 6
APW8715C TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 12 700 6
APW8715D TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 12 700 6
APW8715E TQFN4x4-23 COT 1 2.7 28 0.8 100~1000 30 12 25 8
APW8716 TQFN5x5-30 COT 1 2.7 28 0.8 300~1000 9.7 5.2 700 12
APW8716A TQFN5x5-30 COT 1 2.7 28 0.8 300~1000 9.7 5.2 700 12
APW8716AH TQFN5x5-30 COT 1 2.7 28 0.8 300~1000 9.7 5.2 700 12
APW8741A TDFN3x3-10 CM 1 2.9 5.5 0.6 1000 75 65 460 3
APW8742 TQFN4x4-22A COT 1 2.7 28 0.8 100~1000 22 7 17 10
APW8742S TQFN4x4-22A COT 1 2.7 28 0.8 100~1000 18 5 17 12
APW8743 TQFN3x3-16B COT 2 5 22 0.78
1.05
500 210 90 65 0.5
APW8743C/D/E TQFN3x3-16B COT 2 4.5 22 0.78
1.05
500 210 90 65 0.5
APW8765B VTQFN3x3-12 COT 1 5.5 23 3.3 500 30 15 80 6
APW8765C VTQFN3x3-12 COT 1 5.5 23 5.1 750 30 15 80 6
APW8802 TQFN5x6-28 COT 1 3 25 0.75 500 12 12 400 8
APW8804 TDFN3x3-10 CM 1 2.6 6 0.6 1000 65 55 460 3
APW8804E TDFN3x3-10 CM 1 2.6 5.5 0.6 1000 65 55 65 3
APW8805 TDFN3x3-10 CM 1 2.6 6 0.6 1000 75 55 460 3
APW8805A TDFN3x3-10 CM 1 2.6 6 0.8 1000 75 55 460 3
APW8805B TDFN3x3-10 CM 1 2.6 6 0.8 1000 75 55 460 3
APW8824 TSOT-23-6 CM 1 2.7 5.5 0.6 1500 280 250 25 1
APW8825 SOT-23-6
TDFN2x2-8
CM 1 2.6 6 0.6 1000 110 80 50 3
APW8827 TDFN2x2-8
VTDFN2x2-8
SOT-23-6
CM 1 2.9 5.5 0.6 1000 75 65 65 3
APW8827A TDFN2x2-8
SOT-23-5
SOT-23-6
CM 1 2.9 5.5 0.6 1000 75 65 65 3
APW8827B TDFN2x2-8
SOT-23-6
CM 1 2.9 5.5 0.6 1000 75 65 65 3
APW8827D SOT-23-6
TDFN2x2-8
CM 1 2.9 5.5 0.6 800 75 65 65 3
APW8830 TDFN3x3-10 CM 1 2.6 5.5 0.6 1000 75 65 65 3
APW8830A TDFN3x3-10 CM 1 2.6 5.5 0.6 1000 75 65 65 3
APW8835 TDFN3x3-10 CM 1 4.5 24 0.8 600 70 70 400 3
APW8861 TQNF4x4-32 COT 1 4.5 26 0.75 400~550 75 75 230 8
APW8863 TQNF4x4-32 COT 1 6 21 0.75 550 75 75 280 8
APW8863A TQFN4x4-32 COT 1 4.5 21 0.75 400~550 15 8 160 8
APW8863D TQFN4x4-32 COT 1 4.5 24 0.5 400~600 15 8 160 8
APW8878 TQFN2x3-12 COT 1 5.5 24 5 700 25 12 100 8
APW8878A TQFN2x3-12 COT 1 5.5 24 4.85
5.1
700 25 12 80 8
APW8878B TQFN2x3-12 COT 1 5.5 24 5.1 700 25 12 80 8
APW8879 TQFN2x3-12 COT 1 5.5 24 3.33 700 25 12 80 8
APW8879A TQFN2x3-12 COT 1 5.5 24 3.2
3.33
700 25 12 80 8
APW8879B TQFN2x3-12 COT 1 5.5 24 3.33 700 25 12 80 8
APW9103 TSOT-23-8 CM 1 4.5 18 0.6 500~2000 70 38 - 3
APW9105 TQFN3x2-14 CM 1 4.5 18 0.6 500~2000 40 20 100 6
APW9106 TQFN3x3-14 CM 1 4.5 18 0.6 500~2000 20 11 90 10
APW9109 SOT-23-5 CM 1 2.9 5.5 0.3 1000 75 65 65 3
APW9140 TSOT-23-6A CM 1 4.5 24 0.6 800 60 35 55 3
APW9169C TDFN1x1.5-6 COT 1 2.7 5.5 0.6 2.4 120 80 - 1
APW9170C TDFN2x2-6A
TSOT-23-6A
COT 1 2.7 5.5 0.6 2500 130 80 - 2
APW9114 TSOT-23-8 CM 1 4.5 18 0.6 500~2000 65 35 - 4.3
APW9202/S/L VTQFN2x2-13 CM 2 4.5 18 0.6 500~2000 95
105
50
60
155 2
3
APW9202M VTQFN2x2-13 CM 2 4.5 18 0.6 500~2000 95
105
50
60
155 3
2
APW9208 VTQFN3x2-18 CM 2 2.5 5.5 0.6 1200~3000 18
70
12
35
- 2
6
APW9209 VTQFN3x2-18 CM 2 2.5 5.5 0.6 1200~3000 12
70
8
35
- 2
8
APW9211S VTQFN2x2-13 CM 2 4.5 16 0.6 600 75
95
45
55
155 2
4
APW9213 VTQFN3x2-18 CM 2 2.5 5.5 0.6 1200~3000 45
70
30
35
- 2
4
APW9399 TQFN3x3-20A CM 3 4.5 24 0.6 500~2000 120 30
50
160 1.5
2.5
APW7582
Active
0.6A, 5V Input, Low IQ Buck Converter

Features
  • Input Voltage Range: 2.6V to 5.5V
  • Low Switching Quiescent Current
  • 0.6A Output Current
  • Constant on Time Mode Operation
  • 3MHz Switching Frequency
  • Power-On-Reset Detection on VIN
  • Integrated Soft Start Time
  • Over-Temperature Protection
  • Over-Current Protection
  • Tiny WLCSP 0.90x0.74-5, H=0.33mm Package

General Description
The APW7582 is a synchronous buck converter adopting constant on time control mode. Due to increasing the oscillation to high frequency, the mounting area including peripheral components can be reduced. APW7582 also has low switching quiescent current to improve efficiency and battery-powered equipment using time. The APW7582 is equipped with Power-on-reset, internal soft start and over-current protection, over-temperature into a single low cost WLCSP package.
檔案下載+ 加入洽詢+ 加入比較 +
APW8712F
Active
High Input Voltage 12A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.6V to +12V
- 0.6V Reference Voltage
- ±1% Accuracy Over-Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 22mΩ at VCC=5V N-Channel MOSFET for High Side
  • Integrated 7mΩ at VCC=5V N-Channel MOSFET for Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package

General Description
The APW8712F is a 12A, synchronous, step-down converter with integrated 22mΩ N-channel High-Side MOSFET and 7mΩ Low-Side MOSFET. The APW8712F steps down high voltage to generate low-voltage for chipset or RAM supplies in notebook computers. The APW8712F provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Modulation (PFM), the APW8712F provides very high efficiency over light to heavy loads with loading modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for lownoise requirements. The APW8712F is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8712F has external adjustable soft-start and integrates output discharge method for soft-stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8712F is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW9304H
Active
3-CH Buck Converter, 3-18V Input Voltage, Tiny Package

Features
  • Wide input voltage range:
- Channel 1 and 3 from 1.65V to 18V
- Channel 2 from 3V to 18V
  • 3A/2.5A/1.5A Output Current on Channel1/2/3
  • Typical 0.6V ±1% Internal Reference Voltage
  • Sync Pin Allows Synchronization to an External Clock from 1.8MHz to 2.4MHz
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (60 mΩ) for CH1 High Side
- N-CH MOSFET (90 mΩ) for CH2/3 High Side
- N-CH MOSFET (45 mΩ) for CH1 Low Side
- N-CH MOSFET (50 mΩ) for CH2/3 Low Side
  • Built in OVP, UVP, Current Limit, VIN OVP and OTP
  • Low Cost TQFN 4x4-20D Wettable Flanks Package
  • High Performance or Low Cost Configuration, Auto Mode or FPWM can be set by MODE PIN
  • Spread Spectrum Option and Power On Sequence can be configured by SEQ/SSP PIN

General Description
The APW9304H is a three-channel synchronous mode PWM converter with 3A continuous current capability for one channel and 2.5A continuous current capability for the other channel and 1.5A continuous current capability for the other one channel. Although the switching frequency of the APW9304H is fixed at 2.1MHz, it can also change the switching frequency via the EN/SYNC pin. The APW9304H also provides a 120-degree phase shifting technique and Spread Spectrum option to minimize the noise for reducing EMI. The output voltage of each channel can be adjusted using an external resistor divider. Other features include VIN OVP, VOUT OVP, UVP, current limit, and OTP. The internal switching frequency is set at 2.1MHz. Other features of the part include VIN OVP, OVP, UVP, Current Limit and OTP. The APW9304H is available in a TQFN 4x4-20D wettable flanks package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +
APW7085
Active
2A, 26V, 380kHz, Asynchronous Step-Down Converter

Features
  • Wide Input Voltage from 4.5V to 26V
  • Output Current up to 2A
  • Adjustable Output Voltage from 0.8V to 90% VIN
- 0.8V Reference Voltage
- ±2.5% System Accuracy
  • 100mΩ Integrated P-Channel Power MOSFET
  • High Efficiency up to 91%
- Pulse-Skipping Mode (PSM) / PWM Mode Operation
  • Current-Mode Operation
- Stable with Ceramic Output Capacitors
- Fast Transient Response
  • Power-On-Reset Monitoring
  • Fixed 380kHz Switching Frequency in PWM Mode
  • Built-in Digital Soft-Start
  • Output Current-Limit Protection with Frequency Foldback
  • 70% Under-Voltage Protection
  • Over-Temperature Protection
  • <5µA Quiescent Current During Shutdown
  • SOP-8 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7085 is a 2A, asynchronous, step-down converter with integrated 100mΩ P-channel MOSFET. The device, with current-mode control scheme, can convert 4.5~26V input voltage to the output voltage adjustable from 0.8 to 90% VIN to provide excellent output voltage regulation. The APW7085 regulates the output voltage in automatic PSM/PWM mode operation, depending on the output current, for high efficiency operation over light to full load current. The APW7085 is also equipped with power-onreset, soft-start, and whole protections (under-voltage, over- temperature, and current-limit) into a single package. In shutdown mode, the supply current drops below 5µA. This device, available in a 8-pin SOP-8 package, provides a very compact system solution with minimal external components.
檔案下載+ 加入洽詢+ 加入比較 +
APW7089
Active
4A, 26V, 380kHz, Asynchronous Step-Down Converter

Features
  • Wide Input Voltage from 4.5V to 26V
  • Output Current up to 4A
  • Adjustable Output Voltage from 0.8V to 90% VIN
- 0.8V Reference Voltage
- ±2.5% System Accuracy
  • 80mΩ Integrated P-Channel Power MOSFET
  • High Efficiency up to 91%
- Pulse-Skipping Mode (PSM) / PWM Mode Operation
  • Current-Mode Operation
- Stable with Ceramic Output Capacitors
- Fast Transient Response
  • Power-On-Reset Monitoring
  • Fixed 380kHz Switching Frequency in PWM Mode
  • Built-in Digital Soft-Start
  • Output Current-Limit Protection with Frequency Foldback
  • 70% Under-Voltage Protection
  • Over-Temperature Protection
  • <5µA Quiescent Current During Shutdown
  • Thermal-Enhanced SOP-8P Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7089 is a 4A, asynchronous, step-down converter with integrated 80mΩ P-channel MOSFET. The device, with current-mode control scheme, can convert 4.5~26V input voltage to the output voltage adjustable from 0.8 to 90% VIN to provide excellent output voltage regulation. The APW7089 regulates the output voltage in automatic PSM/PWM mode operation, depending on the output current, for high efficiency operation over light to full load current. The APW7089 is also equipped with power-onreset, soft-start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. In shutdown mode, the supply current drops below 5µA. This device, available in a 8-pin SOP-8P package, provides a very compact system solution with minimal external components and good thermal conductance.
檔案下載+ 加入洽詢+ 加入比較 +
APW7104
Active
1.5MHz, 1A Synchronous Buck Regulator

Features
  • 1A Output Current
  • Wide 2.7V~6.0V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% Duty Cycle
  • 25µA Quiescent Current
  • Integrate Synchronous Rectifier
  • 0.6V Reference Voltage
  • Current-Mode Operation with Internal Compensation
- Stable with Ceramic Output Capacitors
- Fast Line Transient Response
  • Short-Circuit Protection
  • Over-Temperature Protection with Hysteresis
  • Available in SOT-23-5/TSOT-23-5A Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7104 is a 1.5MHz high efficiency monolithic synchronous buck regulator. Design with current mode scheme, the APW7104 is stable with ceramic output capacitor. Input voltage from 2.7V to 6.0V makes the APW7104 ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the using of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need of an external Schottky diode. The APW7104 is available in SOT-23-5/TSOT-23-5A packages.
檔案下載+ 加入洽詢+ 加入比較 +
APW7104A
Active
1.5MHz, 1A Synchronous Buck Regulator

Features
  • 1A Output Current
  • Wide 2.7V~6.0V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% Duty Cycle
  • Integrate Synchronous Rectifier
  • 0.6V Reference Voltage
  • Current-Mode Operation with Internal Compensation
- Stable with Ceramic Output Capacitors
- Fast Line Transient Response
  • Short-Circuit Protection
  • Over-Temperature Protection with Hysteresis
  • Available in SOT-23-5 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7104A is a 1.5MHz high efficiency monolithic synchronous buck regulator. Design with current mode scheme, the APW7104A is stable with ceramic output capacitor. Input voltage from 2.7V to 6.0V makes the APW7104A ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the using of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need of an external Schottky diode. The APW7104A is available in SOT-23-5 packages.
檔案下載+ 加入洽詢+ 加入比較 +
APW7142
Active
3A, 12V, Synchronous-Rectified Buck Converter

Features
  • Wide Input Voltage from 4.3V to 14V
  • Output Current up to 3A
  • Adjustable Output Voltage from 0.8V to VIN
- ±2% System Accuracy
  • 70mΩ Integrated Power MOSFETs
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Current-Mode Operation
- Easy Feedback Compensation
- Stable with Low ESR Output Capacitors
- Fast Load/Line Transient Response
  • Power-On-Reset Monitoring
  • Fixed 500kHz Switching Frequency in PWM Mode
  • Built-In Digital Soft-Start and Soft-Stop
  • Current-Limit Protection with Frequency Foldback
  • 123% Over-Voltage Protection
  • Hiccup-Mode 50% Under-Voltage Protection
  • Over-Temperature Protection
  • <3µA Quiescent Current in Shutdown Mode
  • Small SOP-8 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7142 is a 3A synchronous-rectified Buck converter with integrated 70mΩ power MOSFETs. The APW7142, designed with a current-mode control scheme, can convert wide input voltage of 4.3V to 14V to the output voltage adjustable from 0.8V to VIN to provide excellent output voltage regulation. For high efficiency over all load current range, the APW7142 is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode, which keeps a constant minimum inductor peak current, to reduce switching losses. At heavy load, the IC works in PWM mode, which inductor peak current is programmed by the COMP voltage, to provide high efficiency and excellent output voltage regulation. The APW7142 is also equipped with power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, and current-limit) into a single package. In shutdown mode, the supply current drops below 3µA. This device, available in a 8-pin SOP-8 package, provides a very compact system solution with minimal external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7145
Active
3A, 12V, Synchronous-Rectified Buck Converter

Features
  • Wide Input Voltage from 4.3V to 14V
  • Output Current up to 3A
  • Adjustable Output Voltage from 0.8V to VIN
- ±2% System Accuracy
  • 55mΩ Integrated Power MOSFETs
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Current-Mode Operation
- Easy Feedback Compensation
- Stable with Low ESR Output Capacitors
- Fast Load/Line Transient Response
  • Power-On-Reset Monitoring
  • Fixed 500kHz Switching Frequency in PWM Mode
  • Built-In Digital Soft-Start and Soft-Stop
  • Current-Limit Protection with Frequency Foldback
  • 123% Over-Voltage Protection
  • Hiccup-Mode 50% Under-Voltage Protection
  • Over-Temperature Protection
  • <3µA Quiescent Current in Shutdown Mode
  • SOP-8P and Compact 4mmx4mm DFN-8 (DFN4x4-8) Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7145 is a 3A synchronous-rectified Buck converter with integrated 55mΩ power MOSFETs. The APW7145, designed with a current-mode control scheme, can convert wide input voltage of 4.3V to 14V to the output voltage adjustable from 0.8V to VIN to provide excellent output voltage regulation. For high efficiency over all load current range, the APW7145 is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode, which keeps a constant minimum inductor peak current, to reduce switching losses. At heavy load, the IC works in PWM mode, which inductor peak current is programmed by the COMP voltage, to provide high efficiency and excellent output voltage regulation. The APW7145 is also equipped with power-on-reset, softstart, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, and current-limit) into a single package. In shutdown mode, the supply current drops below 3µA. This device, available SOP-8P and DFN4x4-8 packages, provides a very compact system solution with minimal external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7176
Active
Dual 1.5MHz, 1A Synchronous Step-Down Converter

Features
  • 1A Output Current on Each Channel
  • 2.7V to 5.5V Input Voltage Range
  • 1.5MHz Constant Frequency Operation
  • Low Dropout Operation at 100% Duty Cycle
  • Synchronous Topology
  • 0.6V Low Reference Voltage
  • Current Mode Operation
  • Over-Temperature Protection
  • Over-Current Protection
  • Up to 94% Efficiency
  • Internally Compensated
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7176 consists of two independent 1.5MHz constant frequency, current mode, and PWM step-down converters. Each converter integrates a main switch with a synchronous rectifier for high efficiency without an external Schottky diode. The APW7176 is ideal for powering portable equipment that runs from a single cell LithiumIon (Li+) battery. Each converter can supply 1A of load current from a 2.7V to 5.5V input voltage. The output voltage can be regulated as low as 0.6V. The APW7176 can also run at 100% duty cycle for low dropout applications.
檔案下載+ 加入洽詢+ 加入比較 +
APW7176A
Active
Dual 1.5MHz, 1A Synchronous Step-Down Converter

Features
  • 1A Output Current on Each Channel
  • 2.7V to 5.5V Input Voltage Range
  • 1.5MHz Constant Frequency Operation
  • Low Dropout Operation at 100% Duty Cycle
  • Synchronous Topology
  • 0.6V Low Reference Voltage
  • Current Mode Operation
  • Over-Temperature Protection
  • Over-Current Protection
  • Up to 94% Efficiency
  • Internally Compensated
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7176A consists of two independent 1.5MHz constant frequency, current mode, and PWM step-down converters. Each converter integrates a main switch with a synchronous rectifier for high efficiency without an external Schottky diode. The APW7176A is ideal for powering portable equipment that runs from a single cell Lithium-Ion (Li+) battery. Each converter can supply 1A of load current from a 2.7V to 5.5V input voltage. The output voltage can be regulated as low as 0.6V. The APW7176A can also run at 100% duty cycle for low dropout applications.
檔案下載+ 加入洽詢+ 加入比較 +
APW7178
Active
1.5MHz, 1A Synchronous Buck Regulator

Features
  • 1A Output Current
  • Wide 2.7V~6.0V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% Duty Cycle
  • 25µA Quiescent Current
  • Synchronous Rectifier
  • 0.6V Reference Voltage
  • <0.5µA Input Current During Shutdown
  • Short-Circuit Protection
  • Over-Temperature Protection
  • Available in TDFN2x2-6 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7178 is a 1.5MHz high efficiency monolithic synchronous buck regulator. Design with current mode scheme, the APW7178 is stable with ceramic output capacitor. Input voltage from 2.7V to 6.0V makes the APW7178 ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the using of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need of an external Schottky diode. The APW7178 is available in TDFN2x2-6 packages.
檔案下載+ 加入洽詢+ 加入比較 +
APW7178A
Active
1.5MHz, 1A Synchronous Buck Regulator

Features
  • 1A Output Current
  • Wide 2.7V~6.0V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% Duty Cycle
  • Synchronous Rectifier
  • 0.6V Reference Voltage
  • <0.5µA Input Current During Shutdown
  • Short-Circuit Protection
  • Over-Temperature Protection
  • Available in TDFN2x2-6 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7178A is a 1.5MHz high efficiency monolithic synchronous buck regulator. Design with current mode scheme, the APW7178A is stable with ceramic output capacitor. Input voltage from 2.7V to 6.0V makes the APW7178A ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the using of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need of an external Schottky diode. The APW7178A is available in TDFN2x2-6 packages.
檔案下載+ 加入洽詢+ 加入比較 +
APW7179
Active
Dual 1.5MHz, 1A Synchronous Step-Down Converter

Features
  • 1A Output Current on Each Channel
  • 2.7V to 5.5V Input Voltage Range
  • 1.5MHz Constant Frequency Operation
  • Low Dropout Operation at 100% Duty Cycle
  • Synchronous Topology
  • 0.6V Low Reference Voltage
  • Current Mode Operation
  • Over-Temperature Protection
  • Over-Current Protection
  • Up to 94% Efficiency
  • Internally Compensated
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7179 consists of two independent 1.5MHz constant frequency, current mode, and PWM step-down converters. Each converter integrates a main switch with a synchronous rectifier for high efficiency without an external Schottky diode. The APW7179 is ideal for powering portable equipment that runs from a single cell LithiumIon (Li+) battery. Each converter can supply 1A of load current from a 2.7V to 5.5V input voltage. The output voltage can be regulated as low as 0.6V. The APW7179 can also run at 100% duty cycle for low dropout applications.
檔案下載+ 加入洽詢+ 加入比較 +
APW7179A
Active
Dual 1.5MHz, 1A Synchronous Step-Down Converter

Features
  • 1A Output Current on Each Channel
  • 2.7V to 5.5V Input Voltage Range
  • 1.5MHz Constant Frequency Operation
  • Low Dropout Operation at 100% Duty Cycle
  • Synchronous Topology
  • 0.6V Low Reference Voltage
  • Current Mode Operation
  • Over-Temperature Protection
  • Over-Current Protection
  • Up to 94% Efficiency
  • Internally Compensated
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7179A consists of two independent 1.5MHz constant frequency, current mode, and PWM step-down converters. Each converter integrates a main switch with a synchronous rectifier for high efficiency without an external Schottky diode. The APW7179A is ideal for powering portable equipment that runs from a single cell Lithium-Ion (Li+) battery. Each converter can supply 1A of load current from a 2.7V to 5.5V input voltage. The output voltage can be regulated as low as 0.6V. The APW7179A can also run at 100% duty cycle for low dropout applications.
檔案下載+ 加入洽詢+ 加入比較 +
APW7179C
Active
Dual 1.5MHz, 1A Synchronous Step-Down Converter

Features
  • 1A Output Current on Each Channel
  • 3V to 5.5V Input Voltage Range
  • 1.5MHz Constant Frequency Operation
  • Low Dropout Operation at 100% Duty Cycle
  • Synchronous Topology
  • 0.6V Low Reference Voltage
  • Current Mode Operation
  • Over-Temperature Protection
  • Over-Current Protection
  • High Efficiency
  • Internally Compensated
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7179C consists of two independent 1.5MHz constant frequency, current mode, and PWM step-down converters. Each converter integrates a main switch with a synchronous rectifier for high efficiency without an external Schottky diode. The APW7179C is ideal for powering portable equipment that runs from a single cell Lithium-Ion (Li+) battery. Each converter can supply 1A of load current from a 3V to 5.5V input voltage. The output voltage can be regulated as low as 0.6V. The APW7179C can also run at 100% duty cycle for low dropout applications.
檔案下載+ 加入洽詢+ 加入比較 +
APW7255
Active
Two Channel Regulators and Three Channel Buck Converters PMIC

Features
  • Wide Input Operating Range: 2.9V~6.0V
  • Three Synchronous Buck Regulators for SoC
- Adjustable Output with 1500mA Output for Core Power
- Adjustable Output with 1000mA Output for Memory Power
- Adjustable Output with 1000mA Output for System Power
- 1.5MHz Switching Frequency
- High Efficient up to 93%
  • Tow Low-Dropout Linear Regulators for Sensor:
- Adjustable 300mA Output High PSRR, Low Noise
- Adjustable 300mA Output High PSRR, Low Noise
  • Thermal-Overload Protection
  • Power-OK Indicator after CH2 Ready
  • TQFN3x3-20 Package
  • Lead Free Green Devices Available (RoHS Compliant)

General Description
The APW7255 is a two P-channel low dropout linear regulator and three synchronous buck converter which needs input voltage from 2.9V to 6V. Synchronous buck converter with integrated high side and low side power MOSFET. It is equipped with an automatic PSM/PWM mode operation. At light load, the IC operates in the PSM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. Low dropout linear regulator delivers current up to 300mA to set output voltage, and it also can work with low ESR ceramic capacitors. Typical dropout voltage is only 240mV at 300mA loading. The APW7255 is equipped with Power-on-reset, shutdown control, soft start, over-temperature and currentlimit into a single package to protect the device against wrong logic control and over-temperature and current over-loads. The APW7255 available TQFN3x3-20 provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7301
Active
3A 24V 340kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.5V to 24V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.925V to 20V
  • Intergrated High/Low Side MOSFET
  • PFM/PWM mode Operation
  • Fixed 340kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Programmable Soft-Start
  • Over-Temperature Protection
  • Current-Limit Protection with Frequency Foldback
  • Enable/ShutdownFunction
  • Small SOP-8P Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7301 is a 3A synchronous buck converter with integrated 110mΩ power MOSFETs. The APW7301 design with a current-mode control scheme, can convert wide input voltage of 4.5V to 24V to the output voltage adjustable from 0.925V to 20V to provide excellent output voltage regulation. The APW7301 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM. The APW7301 is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, and current-limit) into a single package. This device, available SOP-8P, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7303
Active
3A 24V 340kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.5V to 24V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.92V to 20V
  • Intergrated N-MOSFET
  • Fixed 340kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Programmable Soft-Start
  • Over-Temperature Protection
  • Current-Limit Protection with Frequency Foldback
  • Enable/Shutdown Function
  • Small SOP-8P Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7303 is a 3A synchronous buck converter with integrated power MOSFETs. The APW7303 design with a current-mode control scheme, can convert wide input voltage of 4.5V to 24V to the output voltage adjustable from 0.92V to 20V to provide excellent output voltage regulation. The APW7303 is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, and current-limit) into a single package. This device, available SOP-8P, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7307
Active
24V 3A 500kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.7V to 24V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.807V to 13V
  • Integrated Low RDS(ON) MOSFETs
  • Fixed 500kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Over-Temperature Protection
  • Current-Limit Protection with HICCUP Mode
  • Small TSOT-23-8A Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7307 is a 3A synchronous buck converter with integrated low RDS(ON) power MOSFETs. The APW7307 design with a current-mode control scheme, can convert wide input voltage of 4.7V to 24V to the output voltage adjustable from 0.807V to 13V to provide excellent output voltage regulation. The APW7307 is equipped advance asynchronous modulation mode operation. Increase efficiency at light load. The APW7307 is also equipped with Power-on-reset, soft start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TSOT-23-8A, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7304
Active
4A 24V 340kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.5V to 24V
  • 4A Peak Output Current
  • Adjustable Output Voltage from 0.8V to 20V
  • Intergrated N-MOSFET
  • Fixed 340kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Programmable Soft-Start
  • Over-Temperature Protection
  • Current-Limit Protection with Frequency Foldback
  • Enable/Shutdown Function
  • Small SOP-8P Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7304 is a 4A synchronous buck converter with integrated power MOSFETs. The APW7304 design with a current-mode control scheme, can convert wide input voltage of 4.5V to 24V to the output voltage adjustable from 0.8V to 20V to provide excellent output voltage regulation. The APW7304 is equipped with an automatic PFM/PWM mode to reduce the switching losses. At heavy load, the IC works in PWM. The APW7304 is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, and current-limit) into a single package. This device, available SOP-8P, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7307A
Active
16V 3A 500kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.7V to 16V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.807V to 13V
  • Integrated Low RDS(ON) MOSFETs
  • Fixed 500kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Over-Temperature Protection
  • Current-Limit Protection with HICCUP Mode
  • Small TSOT-23-8A Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7307A is a 3A synchronous buck converter with integrated low RDS(ON) power MOSFETs. The APW7307A design with a current-mode control scheme, can convert wide input voltage of 4.7V to 16V to the output voltage adjustable from 0.807V to 13V to provide excellent output voltage regulation. The APW7307A is equipped advance asynchronous modulation mode operation. Increase efficiency at light load. The APW7307A is also equipped with Power-on-reset, soft start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TSOT-23-8A, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7309
Active
24V 2A 500kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.7V to 24V
  • 2A Continuous Output Current
  • Adjustable Output Voltage from 0.807V to 13V
  • Integrated Low RDS(ON) MOSFETs
  • Fixed 500kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Over-Temperature Protection
  • Current-Limit Protection with HICCUP Mode
  • Small TSOT-23-8A Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7309 is a 2A synchronous buck converter with integrated low RDS(ON) power MOSFETs. The APW7309 design with a current-mode control scheme, can convert wide input voltage of 4.7V to 24V to the output voltage adjustable from 0.807V to 13V to provide excellent output voltage regulation. The APW7309 is equipped advance asynchronous modulation mode operation. Increase efficiency at light load. The APW7309 is also equipped with Power-on-reset, soft start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TSOT-23-8A, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7313
Active
3A 24V 340kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.5V to 24V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.925V to 20V
  • Intergrated High/Low Side MOSFET
  • PFM/PWM mode Operation
  • Fixed 340kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Programmable Soft-Start
  • Over-Temperature Protection
  • Current-Limit Protection with Frequency Foldback
  • Enable/Shutdown Function
  • Small SOP-8P Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7313 is a 3A synchronous buck converter with integrated 110mΩ power MOSFETs. The APW7313 design with a current-mode control scheme, can convert wide input voltage of 4.5V to 24V to the output voltage adjustable from 0.925V to 20V to provide excellent output voltage regulation. The APW7313 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM. The APW7313 is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, and current-limit) into a single package. This device, available SOP-8P, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7314
Active
24V 2A 500kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.7V to 24V
  • 2A Continuous Output Current
  • Adjustable Output Voltage from 0.807V to 13V
  • Integrated Low RDS(ON) MOSFETs
  • Fixed 500kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Over-Temperature Protection
  • Current-Limit Protection with HICCUP Mode
  • Small TSOT-23-8A Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7314 is a 2A synchronous buck converter with integrated low RDS(ON) power MOSFETs. The APW7314 design with a current-mode control scheme, can convert wide input voltage of 4.7V to 24V to the output voltage adjustable from 0.807V to 13V to provide excellent output voltage regulation. The APW7314 is equipped advance asynchronous modulation mode operation. Increase efficiency at light load. The APW7314 is also equipped with Power-on-reset, soft start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TSOT-23-8A, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7320
Active
High Efficiency 16V, 500kHz Synchronous Step-Down Converter

Features
  • Wide 4.5V to 16V Operating Input Range
  • Low RDS(ON) Internal Power MOSFETs
  • Low Quiescent Current
  • Fast Load Transient Response
  • Fixed 500kHz Switching Frequency
  • Build-in soft start function
  • Output Adjustable from 0.6V to 5V
  • Protection
- Output Over-Voltage Protection
- Output Under-Voltage Protection
- Over-Current Protection
- Input Over-Voltage Protection
- Over-Temperature Protection
  • Available in TSOT-23-6 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7320 is a high efficiency synchronous buck converter with integrated 80mΩ/52mΩ of upper/lower power MOSFET. The APW7320 design with a COT-mode control scheme, can convert wide input voltage of 4.5V to 16V to the output voltage adjustable from 0.6V to 5V to provide excellent output voltage regulation. The APW7320 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. The APW7320 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. The APW7320 is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, overvoltage, under-voltage, over-current and input overvoltage) into a single package. This device, available in TSOT-23-6 package, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7322/A
Active
2A, 5V, 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 94%
  • Adjustable Output Voltage from 0.8V to VPVDD
  • Operating from 2.9 to 6V Supply
  • Integrated 85mΩ High Side / 75mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Stable with Low ESR Ceramic Capacitors
  • Current up to 2A
  • Power-On-Reset Detection on VCC and VIN
  • Mode Selestion:
APW7322: Automatic PFM/PWM
APW7322A: Forced PWM
  • Integrate Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High/Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • Available in SOP-8P and TDFN3x3-10 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7322/A is a synchronous buck converters with integrated 85mΩ high side and 75mΩ low side power MOSFETs. The APW7322/A with a current-mode control scheme can convert wide input voltage of 2.9V to 6V to the output voltage adjustable from 0.8V to 6V to provide excellent output voltage regulation. The APW7322/A is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW7322/A is also equipped with Power-on-reset, soft start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available in SOP-8, TDFN3x3-10 packages, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7323/A
Active
3.2A, 5V, 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 94%
  • Adjustable Output Voltage from 0.8V to VPVDD
  • Operating from 2.9 to 6V Supply
  • Integrated 85mΩ High Side / 75mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Stable with Low ESR Ceramic Capacitors
  • Current up to 3.2A
  • Power-On-Reset Detection on VCC and VIN
  • Model Selection:
APW7323: Automatic PFM/PWM
APW7323A: Forced PWM
  • Integrate Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High/Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • Available in SOP-8P and TDFN3x3-10 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7323/A is a synchronous buck converters with integrated 85mΩ high side and 75mΩ low side power MOSFETs. The APW7323/A with a current-mode control scheme can convert wide input voltage of 2.9V to 6V to the output voltage adjustable from 0.8V to 6V to provide excellent output voltage regulation. The APW7323/A is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW7323/A is also equipped with Power-on-reset, soft start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available in SOP-8P and TDFN3x3-10 packages, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7325
Active
5A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic PFM/PWM Mode Operation
  • Adjustable Output Voltage from 0.6V to VPVDD
  • Integrated 65mΩ High Side / 55mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VDD and PVDD
  • Integrated Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High/Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • Small SOP-8P Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7325 is a 5A synchronous buck converter with integrated 65mΩ high side and 55mΩ low side power MOSFETs. The APW7325, design with a current-mode control scheme, can convert wide input voltage of 2.6V to 6V to the output voltage adjustable from 0.6V to 6V to provide excellent output voltage regulation. The APW7325 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. At PWM mode, the switching frequency is set by the external resistor. The APW7325 is also equipped with Power-on-reset, softstart, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available SOP-8P, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7328
Active
3.5A, 5V, 1.2MHz Synchronous Step-Down Converter

Features
  • 3.5A Continuous Output Current
  • Operating Voltage Range: 2.7V~5.5V
  • Fixed Switching Frequency: 1.2MHz (PWM)
  • 0.6V Reference Voltage
  • PSM/PWM Operation
  • Low RDS(ON) Internal Power MOSFETs
  • OCP Protection and Thermal Shutdown
  • Internal Compensation
  • Short Circuit Protection with Hiccup mode
  • Fold-back Switching Frequency
  • Over Temperature Protection
  • Input Over Voltage Protection
  • TQFN2x2-12A package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7328 is a high efficiency monolithic synchronous buck converter. APW7328 operates with a constant 1.2MHz switching frequency and using the inductor current as a controlled quantity in the current mode architecture. The 2.7V to 5.5V input voltage range makes the APW7328 ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.2MHz operating frequency allows the use of small surface mount inductors and capacitors.
檔案下載+ 加入洽詢+ 加入比較 +
APW7336
Active
2A 24V 340kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.5V to 24V
  • 2A Continuous Output Current
  • Adjustable Output Voltage from 0.8V to 20V
  • Intergrated High/Low Side MOSFET
  • PFM/PWM mode Operation
  • Fixed 340kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Programmable Soft-Start
  • Over-Temperature Protection
  • Current-Limit Protection with Frequency Foldback
  • Enable/Shutdown Function
  • Small TDFN3x3-10 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7336 is a 2A synchronous buck converter with integrated power MOSFETs. The APW7336 design with a current-mode control scheme, can convert wide input voltage of 4.5V to 24V to the output voltage adjustable from 0.8V to 20V to provide excellent output voltage regulation. The APW7336 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM. The APW7336 is also equipped with Power-on-reset, softstart, soft-stop, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7340A
Active
High Efficiency 16V, 1400kHz Synchronous Step-Down Converter

Features
  • Wide 4.5V to 16V Operating Input Range
  • Low RDS(ON) Internal Power MOSFETs
  • Low Quiescent Current
  • Fast Load Transient Response
  • Fixed 1400kHz Switching Frequency
  • Output Adjustable from 0.6V to 5V
  • Protection
- Output Over-Voltage Protection
- Output Under-Voltage Protection
- Over-Current Protection
- Input Over-Voltage Protection
- Over-Temperature Protection
  • Available in TSOT-23-6 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7340A is a high efficiency synchronous buck converter with integrated 100m/70mΩ of upper/lower power MOSFET. The APW7340A design with a COT-mode control scheme, can convert wide input voltage of 4.5V to 18V to the output voltage adjustable from 0.6V to 5V to provide excellent output voltage regulation. APW7340A is forcePWM operation. The APW7340A is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, overvoltage, under-voltage, over-current and input overvoltage) into a single package. This device, available in TSOT-23-6 package, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7341A
Active
High Efficiency 16V, 1400kHz Synchronous Step-Down Converter

Features
  • Wide 4.5V to 16V Operating Input Range
  • Low RDS(ON) Internal Power MOSFETs
  • Low Quiescent Current
  • Fast Load Transient Response
  • Fixed 1400kHz Switching Frequency
  • Output Adjustable from 0.6V to 5V
  • Protection
- Output Over-Voltage Protection
- Output Under-Voltage Protection
- Over-Current Protection
- Input Over-Voltage Protection
- Over-Temperature Protection
  • Available in TSOT-23-6 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7341A is a high efficiency synchronous buck converter with integrated 80m/52mΩ of upper/lower power MOSFET. The APW7341A design with a COT-mode control scheme, can convert wide input voltage of 4.5V to 18V to the output voltage adjustable from 0.6V to 5V to provide excellent output voltage regulation. The APW7341A is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, overvoltage, under-voltage, over-current and input overvoltage) into a single package. This device, available in TSOT-23-6 package, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7400
Active
High Efficiency 16V, 2A, 650kHz Synchronous Step-Down Converter

Features
  • Wide 4.5V to 16V Operating Input Range
  • Low RDS(ON) Internal Power MOSFETs
  • Low Quiescent Current
  • Fast Load Transient Response
  • Fixed 650kHz Switching Frequency
  • Build-in soft start function
  • Output Adjustable from 0.765V to 5V
  • Protection
- Output Over-Voltage Protection
- Output Under-Voltage Protection
- Over-Current Protection
- Input Over-Voltage Protection
- Over-Temperature Protection
  • Available in FC-TSOT-23-6 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7400 is a high efficiency synchronous buck converter with integrated 90m/56mΩ of upper/lower power MOSFET. The APW7400 design with a COT-mode control scheme, can convert wide input voltage of 4.5V to 18V to the output voltage adjustable from 0.765V to 5V to provide excellent output voltage regulation. The APW7400 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. The APW7400 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. The APW7400 is also equipped with Power-on-reset, softstart, and whole protections (over-temperature, overvoltage, under-voltage, over-current and input overvoltage) into a single package. This device, available in FC-TSOT-23-6 package, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7408
Active
1.3A, 5V Input, 1MHz Synchronous Buck Converter

Features
  • Typical 0.6V Internal Reference Voltage
  • Automatic Skip/PWM Mode Operation
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrated Soft Start and Output Discharge
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High/Low Side Current Limit
  • Enable/Shutdown Function
  • Small SOT-23-5 packages
  • Lead Free and Green Devices Available (RoHS compliant)

General Description
The APW7408 is a 1.3A synchronous buck converter that uses current-mode control scheme to convert wide input voltage of 2.9V to 5.5V to outputs as low as 0.6V while providing excellent output voltage regulation. The APW7408 operates in Automatic Skip/PWM Mode operation and is also equipped with Power-on-reset, internal soft start and complete protections (under-voltage, over-voltage, over-temperature and current-limit) into a single low cost SOT-23-5 package. The IC also provides output capacitor discharge when it is disabled via the internal low side MOSFET.
檔案下載+ 加入洽詢+ 加入比較 +
APW7408B
Active
1.3A, 5V Input, 1.4MHz Synchronous Buck Converter

Features
  • Typical 0.6V Internal Reference Voltage
  • Force PWM Mode Operation
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrated Soft Start and Output Discharge
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High/Low Side Current Limit
  • Enable/Shutdown Function
  • Small SOT-23-5 packages
  • Lead Free and Green Devices Available (RoHS compliant)

General Description
The APW7408B is a 1.3A synchronous buck converter that uses current-mode control scheme to convert wide input voltage of 2.9V to 5.5V to outputs as low as 0.6V while providing excellent output voltage regulation. The APW7408B operates in Force PWM mode operation. The internal switching frequency is set at 1.4MHz while the EN/SYNC pin supports external clock synchronization, and is also equipped with Power-on-reset, internal soft start and complete protections (under-voltage, over-voltage, over-temperature and current-limit) into a single low cost SOT-23-5 package. The IC also provides output capacitor discharge when it is disabled via the internal low side MOSFET.
檔案下載+ 加入洽詢+ 加入比較 +
APW7410
Active
High Efficiency Output 1A, 2.2MHz Buck Converter

Features
  • Wide Input Voltage from 2.5V to 6.0V
  • 0.6V to VIN Adjustable Output Voltage
  • Optional fixed output voltage 1.8V or 2.5V
  • Up to 95% Efficiency
  • 1A Output Current
  • 50uA Operating Quiescent Current
  • 100% Duty Cycle for Lowest Dropout
  • Output Discharge Function
  • 2.2MHz Switching Frequency
  • Power Good Output
  • PWM/PFM Auto Switch
  • Thermal Shutdown Protection
  • Hiccup Short-Circuit Protection
  • Lead Free Green Devices Available (RoHS)

General Description
APW7410 is a high-frequency 1A synchronous buck converter with integrated 75mΩ high side and 50mΩ low side power MOSFET. The APW7410, design with a COT control scheme, can convert wide input voltage of 2.5V to 6V to the output voltage adjustable from 0.6V to 4V to provide excellent output voltage regulation. The APW7410 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW7410 is also equipped with Power-on-reset, Soft start, Enable/disable and whole protections (over-voltage, under-voltage, over-temperature and current-limit) into a single package. This device, available DFN1.5x1.5-6 and, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7415
Active
24V 3A 500kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 4.7V to 24V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.791V to 13V
  • Integrated Low RDS(ON) MOSFETs
  • Fixed 500kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Over-Temperature Protection
  • Current-Limit Protection with HICCUP Mode
  • Small TSOT-23-8A Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7415 is a 3A synchronous buck converter with integrated low RDS(ON) power MOSFETs. The APW7415 design with a current-mode control scheme, can convert wide input voltage of 4.7V to 24V to the output voltage adjustable from 0.791V to 13V to provide excellent output voltage regulation. The APW7415 is equipped advance asynchronous modulation mode operation. Increase efficiency at light load. The APW7415 is also equipped with Power-on-reset, soft start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TSOT-23-8A, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7415S
Active
24V 3A 500kHz Synchronous Buck Converter

Features
  • Wide Input Voltage from 7V to 24V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.791V to 13V
  • Integrated Low RDS(ON) MOSFETs
  • Fixed 500kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Over-Temperature Protection
  • Current-Limit Protection with HICCUP Mode
  • Small TSOT-23-8A Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7415S is a 3A synchronous buck converter with integrated low RDS(ON) power MOSFETs. The APW7415S design with a current-mode control scheme, can convert wide input voltage of 7V to 24V to the output voltage adjustable from 0.791V to 13V to provide excellent output voltage regulation. The APW7415S is equipped advance asynchronous modulation mode operation. Increase efficiency at light load. The APW7415S is also equipped with Power-on-reset, soft start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TSOT-23-8A, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7435
Active
18V Input, Dual 6A and 3A Synchronous Buck with Sync Pin

Features
  • Wide Input Voltage from 4.5V to 18V
  • 6A/3A Output Current on Channel1/2
  • Low IQ=150uA (typ.) per channel supply to improve Light Load Efficiency at Sync off
  • Typical 0.6V ±1% Internal Reference Voltage
  • Sync Pin Allows Synchronization to an External Clock from 500kHz to 2MHz
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (35mΩ) for CH1 High Side
- N-CH MOSFET (20mΩ) for CH1 Low Side
- N-CH MOSFET (75mΩ) for CH2 High Side
- N-CH MOSFET (30mΩ) for CH2 Low Side
  • Independent External Soft-Start Control for each channel
  • Separate EN and for Easy Sequencing
  • PG pin indicating both Channels Power Good
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TQFN4x4-28B package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7435 is a two-channel synchronous mode PWM converter with 6A continuous current capability for one channel and 3A continuous current capability for the other one. Each channel of the APW7435 has independent enable and soft-start control pins, and It also allows the two regulators to start together by using the same enable signal and the same soft-start capacitor. Although the switching frequency of the APW7435 is fixed at 600kHz, it can also change the switching frequency via the SYNC pin. The APW7435 also provides a 180-degree phase shifting technique to minimize switching noise. The output voltage of each channel can be adjusted using an external resistor divider. Other features include UVP, current limit, and OTP. The APW7435 is available in a TQFN4x4-28B package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +
APW7436
Active
3-CH Buck Converter, 4.5-18V Input Voltage, Tiny Package

Features
  • Wide Input Voltage from 4.5V to 18V
  • 2.5A/1.5A/1.5A Output Current on Channel1/2/3
  • Low IQ=160μA (typ.) per channel supply to improve Light Load Efficiency at Sync off
  • Typical 0.6V ±1%Internal Reference Voltage
  • Sync Pin Allows Synchronization to an External
  • Clock from 500kHz to 2MHz
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (120mΩ) for CH1/2/3 High Side
- N-CH MOSFET (30mΩ) for CH1 Low Side
- N-CH MOSFET (50mΩ) for CH2/3 Low Side
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TQFN3x3-20A package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7436 is a three-channel synchronous mode PWM converter with 2.5A continuous current capability for one channel and 1.5A continuous current capability for the other two channels. Although the switching frequency of the APW7436 is fixed at 600kHz, it can also change the switching frequency via the SYNC pin. The APW7436 also provides a 120-degree phase shifting technique to minimize switching noise. The output voltage of each channel can be adjusted using an external resistor divider. Other features include OVP, UVP, current limit, and OTP. The APW7436 is available in a TQFN3x3-20A package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +
APW7437
Active
18V Input, Dual 6A and 3A Synchronous Buck with Sync Pin

Features
  • Wide Input Voltage from 4.5V to 18V
  • 6A/3A Output Current on Channel 1/2
  • Low IQ=150uA (typ.) per channel supply to improve Light Load Efficiency at Sync off
  • Typical 0.6V +1% Internal Reference Voltage
  • Easy to use I2C interface
- Programmable VOUT by control VFB Reference Voltage from 408~790.5mV in 1.5mV steps
- Adjustable Frequency in 4 steps, 500kHz, 600kHz, 800kHz and 1.2MHz
- Adjustable Voltage Step Slew Rate in 3 steps, 0.75mV/uSec, 1.5mV/uSec, 3mV/uSec
- Selectable PSM/PWM mode or PWM mode only
- Support 8 sets of Slave address by an resistor
- Independent salve address for each channel
- I2C Control Function: Soft-Enable and Soft-Reset
  • Sync Pin Allows Synchronization to an External Clock from 500kHz to 2MHz
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (28mW) for CH1 High Side
- N-CH MOSFET (16mW) for CH1 Low Side
- N-CH MOSFET (70mW) for CH2 High Side
- N-CH MOSFET (25mW) for CH2 Low Side
  • Independent External Soft-Start Control for each channel
  • Separate EN and for Easy Sequencing
  • PG pin indicating both Channels Power Good
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TQFN5x5-28 package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7437 is a two-channel synchronous mode PWM converter with 6A continuous current capability for one channel and 3A continuous current capability for the other one. Each channel of the APW7437 has independent enable and soft-start control pins, and It also allows the two regulators to start together by using the same enable signal and the same soft-start capacitor. In addition to changing the switching frequency through the I2C function, the APW7437 can also synchronize the switching frequency with an external clock frequency through the SYNC pin. The APW7437 also provides a 180-degree phase shifting technique to minimize switching noise. The output voltage of each channel can be adjusted using an external resistor divider or by adjusting the internal reference voltage through I2C. Other features include UVP, current limit, and OTP. The APW7437 is available in a TQFN5x5-28 package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +
APW7438A
Active
7A Constant On Time Synchronous Buck Regulator with I2C Production

Features
  • Pseudo frequency COT control
  • Extremely fast line/load transient response
  • I2C for output adjustment (3.4 Mbps)
  • 1.2 MHz switching frequency
  • Extremely low-RDSON MOSFETS
  • Input voltage rail 2.7V to 6V
  • Up to 7A output current
  • Power save mode for light-load efficiency
  • UVLO, OVP, and OCP
  • -40°C to 85°C ambient temperature
  • Available in QFN 2mm x 3mm 14 package
  • RoHS compliant

General Description
The APW7438A is a digitally controlled step-down regulator IC with an integrated 20mΩ high-side P-channel MOSFET and an 8mΩ low-side N-channel MOSFET. It features ANPEC's proprietary COT-mode control scheme for near-instantaneous correction to line/load transients for a voltage range of 2.7V to 6V, and 7A with constant frequency. The APW7438A is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses and provides high efficiency over light to heavy loads with loading-modulated frequency. The APW7438A has an I2C serial interface port for output voltage margining and monitoring, if required (it can also operate in default mode). In addition it includes robust fault monitoring functions. The APW7438A is available in 0.8V default output voltage (no voltage divider is necessary) which can be changed from 0x01 Register.
檔案下載+ 加入洽詢+ 加入比較 +
APW7504R
Active
1.5MHz, 1.2A Synchronous Buck Regulator

Features
  • Up to 1.2A Peak Output Current
  • Wide 3V~5.5V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% Duty Cycle
  • Synchronous Rectifier
  • 0.2V Reference Voltage
  • <0.5µA Input Current During Shutdown
  • Over-Temperature Protection
  • Available in TDFN2x2-6 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7504R is a 1.5MHz high efficiency monolithic synchronous buck regulator. Design with current mode scheme, the APW7504R is stable with ceramic output capacitor. Input voltage from 3V to 5.5V makes the APW7504R ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the using of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need of an external Schottky diode. The APW7504R is available in TDFN2x2-6 package.
檔案下載+ 加入洽詢+ 加入比較 +
APW7506A
Active
1.5MHz, 1A Synchronous Buck Regulator

Features
  • 1A Output Continuous Current
  • 1.2A Output Peak Current
  • Wide 3V~5.5V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% Duty Cycle
  • Integrate Synchronous Rectifier
  • 0.6V Reference Voltage
  • Current-Mode Operation with Internal Compensation
- Stable with Ceramic Output Capacitors
- Fast Line Transient Response
  • Short-Circuit Protection
  • Over-Temperature Protection with Hysteresis
  • Available in SOT-23-5/TSOT-23-5A Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7506A is a 1.5MHz high efficiency monolithic synchronous buck regulator. Design with current mode scheme, the APW7506A is stable with ceramic output capacitor. Input voltage from 3V to 5.5V makes the APW7506A ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the using of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need of an external Schottky diode. The APW7506A is available in SOT-23-5/TSOT-23-5A packages.
檔案下載+ 加入洽詢+ 加入比較 +
APW7506C
Active
1.5MHz, 1A Synchronous Buck Regulator

Features
  • 1A Output Continuous Current
  • 1.2A Output Peak Current
  • Wide 3V~5.5V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% Duty Cycle
  • 30µA Quiescent Current
  • Integrate Synchronous Rectifier
  • 0.6V Reference Voltage
  • Current-Mode Operation with Internal Compensation
- Stable with Ceramic Output Capacitors
- Fast Line Transient Response
  • Short-Circuit Protection
  • Over-Temperature Protection with Hysteresis
  • Available in SOT-23-5/TSOT-23-5A Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7506C is a 1.5MHz high efficiency monolithic synchronous buck regulator. Design with current mode scheme, the APW7506C is stable with ceramic output capacitor. Input voltage from 3V to 5.5V makes the APW7506C ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the using of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need of an external Schottky diode. The APW7506C is available in SOT-23-5/TSOT-23-5A packages.
檔案下載+ 加入洽詢+ 加入比較 +
APW7514
Active
24V 2A 500kHz Synchronous Buck Converter With Adj. Soft Start

Features
  • Wide Input Voltage from 4.5V to 24V
  • 2A Continuous Output Current
  • Adjustable Output Voltage from 0.807V to 13V
  • Integrated Low RDS(ON) MOSFETs
  • Fixed 500kHz Switching Frequency
  • Stable with Low ESR Ceramic Output Capacitors
  • Power-On-Reset Detection
  • Over-Temperature Protection
  • Current-Limit Protection with HICCUP Mode
  • Programmable Soft-Start
  • Small TSOT-23-8A Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW7514 is a 2A synchronous buck converter with integrated low RDS(ON) power MOSFETs. The APW7514 design with a current-mode control scheme, can convert wide input voltage of 4.5V to 24V to the output voltage adjustable from 0.807V to 13V to provide excellent output voltage regulation. The APW7514 is equipped advance asynchronous modulation mode operation. Increase efficiency at light load. The APW7514 is also equipped with Power-on-reset, soft start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. This device, available TSOT-23-8A, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7533
Active
HV Asynchronous Step-Down Converter with Bypass

Features
  • Wide Input Voltage from 4.5V to 26V
  • Output Current up to 3A
  • Adjustable Output Voltage from 0.8V to 100% VIN
- 0.8V Reference Voltage
- ±2.5% System Accuracy
  • 22mΩ Integrated P-Channel Power MOSFET
  • High Efficiency up to 91%
- Pulse-Skipping Mode (PSM) / PWM Mode Operation
  • Current-Mode Operation
- Stable with Ceramic Output Capacitors
- Fast Transient Response
  • Power-On-Reset Monitoring
  • Fixed 380kHz Switching Frequency in PWM Mode
  • Built-in Digital Soft-Start
  • Output Current-Limit Protection with Frequency Foldback
  • 70% Under-Voltage Protection
  • Over-Temperature Protection
  • <5µA Quiescent Current During Shutdown
  • Thermal-Enhanced TDFN-5x5-16 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW7533 is a 3A, asynchronous, step-down converter with integrated 22mΩ P-channel MOSFET. The device, with current-mode control scheme, can convert 4.5~26V input voltage to the output voltage adjustable from 0.8 to 100% VIN to provide excellent output voltage regulation. The APW7533 regulates the output voltage in automatic PSM/PWM mode operation, depending on the output current, for high efficiency operation over light to full load current. The APW7533 is also equipped with power-onreset, soft-start, and whole protections (under-voltage, over-temperature, and current-limit) into a single package. In shutdown mode, the supply current drops below 5mA. This device, available in a TDFN-5x5-16 package, provides a very compact system solution with minimal external components and good thermal conductance.
檔案下載+ 加入洽詢+ 加入比較 +
APW7564
Active
5V/0.3A, Ultra Low Iq Buck Converter

Features
  • Wide Input Voltage from 2.7V to 5.5V
  • 3uA Low Quiescent Current at switching state
  • 2% Output Voltage Accuracy
  • Output Discharge Function
  • 1.5MHz Switching Frequency
  • Over Temperature Protection
  • Hiccup Short-Circuit Protection
  • I2C Interface
- Programmable Output Voltage from 0.5V to 1.13V (10mV/Step)
- Adjustable Output Voltage Ramp Slew Rate
  • Tiny WLCSP 0.8x1.14-6 Package

General Description
APW7564 is a high-frequency synchronous buck converter with I2C Interface. The APW7564, design with a COT control scheme, can convert wide input voltage of 2.7V to 5.5V to the output voltage adjustable from 0.5V to 1.13V by I2C to provide an efficient, flexible DC/DC solution. The APW7564 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW7564 is also equipped with Power-on-reset, Soft start, Enable/Shutdown and whole protections (under-voltage, current-limit and over-temperature) into a tiny package. This device, available WLCSP 0.8x1.14-6 package and provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW7705A/B/C/D
Active
5 Buck Converter+ 1 LDO PMU With Temperature Sensor

Features
  • Wide Input Operating Range: 2.7~5.5V
  • I2C Interface
  • Random and Sequential Read Mode
  • Automatic Address Incrementing
  • Regulators with Programmable DC Set Point and Soft-start
  • Programmable Bucks and LDO and all Regulators with Auto Discharge Function and Reset
  • ±1% Feedback Voltage Accuracy
  • Two Pins to Select Four Sets of DC Voltage
  • Programmable VOUT, Power-up Sequence, Reset IC Delay Time and Enable
  • Integrated Voltage Monitor with Digital Filters
  • TQFN5x5-36 Package
  • Lead Free Green Devices Available (RoHS Compliant)

General Description
The AWP7705A/B/C/D is a PMU for SSD and Docking station application. It contains 5 buck converters, one LDO regulator and one temperature ADC. Each buck and LDO is independent with each other and the power on sequence can be programmed while their regulated voltages can be programmed too. All programming can be done via I2C interface. The ADC can get the external temperature information by TS pin and report the current temperature data to a register. The temperature/data conversion rate and the temperature high and low alert threshold can be adjusted via I2C bus. All buck converters equip PWM/PFM mode. When in light load, the buck converter can enter PFM mode for boosting efficiency. When in PFM mode, the output ripple could slightly bigger than in PWM mode. If smaller output ripple is desired, the PFM mode can be disabled via I2C interface. Each buck converter operates in synchronous PWM mode in heavy load, the synchronous rectification MOSFET can be disabled via I2C. The AWP7705A/B/C/D is available in TQFN5x5-36 package.
檔案下載+ 加入洽詢+ 加入比較 +
APW8712
Active
High Input Voltage 8A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 9mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-22 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8712 is a 8A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mΩ Low-Side MOSFET. The APW8712 steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8712 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8712 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8712 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8712 has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8712 is available in TQFN4x4-22 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8712E
Active
High Input Voltage 10A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 10A Continous Output Current
  • 12A Peak Output Current
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 22mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 7mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-22A 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8712E is a 10A, synchronous, step-down converter with integrated 22mΩ N-channel High-Side MOSFET and 7mΩ Low-Side MOSFET. The APW8712E steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8712E provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8712E provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8712E is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8712E has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. TheAPW8712E is available in TQFN4x4-22A (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713
Active
High Input Voltage 8A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- +1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mW at VCC=5V N-Channel MOSFET For High Side
  • Integrated 9mW at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713 is a 8A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mW Low-Side MOSFET. The APW8713 steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8713 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8713 has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713 is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713A
Active
High Input Voltage 8A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5.3V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at LDO=5V N-Channel MOSFET For High Side
  • Integrated 9mΩ at LDO=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713A is a 8A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mΩ Low-Side MOSFET. The APW8713A steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713A provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713A provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8713A is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VLDO to prevent wrong operation during power-on. The APW8713A has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713A is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713B
Active
High Input Voltage 8A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5.3V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at LDO=5V N-Channel MOSFET For High Side
  • Integrated 9mΩ at LDO=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713B is a 8A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mΩ Low-Side MOSFET. The APW8713B steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713B provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713B provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8713B is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VLDO to prevent wrong operation during power-on. The APW8713B has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713B is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713C
Active
High Input Voltage 10A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 9mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713C is a 10A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mΩ Low-Side MOSFET. The APW8713C steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713C provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713C provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for lownoise requirements. The APW8713C is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8713C has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713C is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713D
Active
High Input Voltage 10A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5.3V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 27mΩ at LDO=5V N-Channel MOSFET For High Side
  • Integrated 7mΩ at LDO=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713D is a 10A, synchronous, step-down converter with integrated 27mΩ N-channel High-Side MOSFET and 7mΩ Low-Side MOSFET. The APW8713D steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713D provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713D provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8713D is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VLDO to prevent wrong operation during power-on. The APW8713D has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713D is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713E
Active
High Input Voltage 8A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 9mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713E is a 8A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mΩ Low-Side MOSFET. The APW8713E steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713E provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713E provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8713E is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8713E has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713E is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713F
Active
High Input Voltage 12A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.6V to +12V
- 0.6V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 9mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • Output no Discharge when EN Low
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713F is a 12A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mΩ Low-Side MOSFET. The APW8713F steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713F provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713F provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8713F is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8713F has external adjustable soft-start, a soft-start ramps up the output voltage with programmable timing to reduce the start-up current. The APW8713F is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713CA
Active
High Input Voltage 10A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 9mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713CA is a 10A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 9mΩ Low-Side MOSFET. The APW8713CA steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713CA provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713CA provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for lownoise requirements. The APW8713CA is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8713CA has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713CA is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8713DA
Active
High Input Voltage 10A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5. 3V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 27mΩ at LDO=5V N-Channel MOSFET For High Side
  • Integrated 7mΩ at LDO=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8713DA is a 10A, synchronous, step-down converter with integrated 27mΩ N-channel High-Side MOSFET and 7mΩ Low-Side MOSFET. The APW8713DA steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8713DA provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8713DA provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for lownoise requirements. The APW8713DA is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VLDO to prevent wrong operation during power-on. The APW8713DA has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8713DA is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8714D
Active
High Input Voltage 6A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.6V to +12V
- 0.6V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-22 4mmx4mm package

General Description
The APW8714D is a 6A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8714D steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8714D provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8714D provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8714D is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8714D has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8714D is available in TQFN4x4-22 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8714E
Active
High Input Voltage 6A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-22 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8714E is a 6A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8714E steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8714E provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8714E provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8714E is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8714E has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8714E is available in TQFN4x4-22 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8715
Active
High Input Voltage 6A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8715 is a 6A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8715 steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8715 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8715 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8715 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8715 has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8715 is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8715A
Active
High Input Voltage 6A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5.3V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at LDO=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ at LDO=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8715A is a 6A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8715A steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8715A provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8715A provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8715A is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VLDO to prevent wrong operation during power-on. The APW8715A has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8715A is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8715C
Active
High Input Voltage 6A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8715C is a 6A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8715C steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8715C provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8715C provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8715C is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8715C has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8715C is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8715D
Active
High Input Voltage 6A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5.3V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at LDO=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ at LDO=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8715D is a 6A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8715D steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8715D provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8715D provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8715D is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VLDO to prevent wrong operation during power-on. The APW8715D has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8715D is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8715E
Active
High Input Voltage 6A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 30mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-23 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8715E is a 6A, synchronous, step-down converter with integrated 30mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8715E steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8715E provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8715E provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8715E is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8715E has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8715E is available in TQFN4x4-23 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8716
Active
High Input Voltage 12A PWM Converter With Adj. Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 300kHz to 1000kHz
  • Integrated 9.7mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 5.2mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-30 5mmx5mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8716 is a 12A, synchronous, step-down converter with integrated 9.7mΩ N-channel High-Side MOSFET and 5.2mΩ Low-Side MOSFET. The APW8716 steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8716 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8716 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8716 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8716 has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8716 is available in TQFN5x5-30 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8716A
Active
High Input Voltage 12A PWM Converter With Adjustable Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 300kHz to 1000kHz
  • Integrated 9.7mΩ at LDO=5V N-Channel MOSFET For High Side
  • Integrated 5.2mΩ at LDO=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-30 5mmx5mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8716A is a 12A, synchronous, step-down converter with integrated 9.7mΩ N-channel High-Side MOSFET and 5.2mΩ Low-Side MOSFET. The APW8716A steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8716A provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8716A provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8716A is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on LDO to prevent wrong operation during power-on. The APW8716A has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8716A is available in TQFN5x5-30 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8716AH
Active
High Input Voltage 12A PWM Converter With Adjustable Soft Start

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- ±1% Accuracy Over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 20mA Low Dropout Regulator (LDO) with Fixed 5V Output
  • Power-On-Reset Monitoring on LDO pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 300kHz to 1000kHz
  • Integrated 9.7mΩ at LDO=5V N-Channel MOSFET for High Side
  • Integrated 5.2mΩ at LDO=5V N-Channel MOSFET for Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Powe Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-30 5mmx5mm package
  • Lead Free and Green Device Available (RoHS Compliant)
  • Design Reference for AECQ100 Grade 1 Compliant

General Description
The APW8716AH is a 12A, synchronous, step-down converter with integrated 9.7mΩ N-channel High-Side MOSFET and 5.2mΩ Low-Side MOSFET. The APW8716AH steps down high voltage to generate lowvoltage for chipset or RAM supplies in notebook computers. The APW8716AH provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Modulation (PFM), the APW8716AH provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8716AH is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on LDO to prevent wrong operation during power-on. The APW8716AH has external adjustable soft-start and integrates output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8716AH is available in TQFN5x5-30 (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8741A
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Force PWM Mode Operation
  • Integrated 75mΩ High Side / 65mΩ Low Side MOSFETs
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VCC and VIN
  • Integrated Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • TDFN3x3-10 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8741A is a 3A synchronous buck converter with integrated 75mΩ high side and 65mΩ low side power MOSFETs. The APW8741A, design with a current-mode control scheme, can convert wide input voltage of 2.9V to 5.5V to provide excellent output voltage regulation. The APW8741A is equipped with an Force PWM mode operation. The APW8741A is at PFM mode before POK goes high, in normal operation, IC works in Force PWM mode. The APW8741A is also equipped with Power-on-reset, softstart, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8742
Active
High Input Voltage 10A PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- +1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 10A Continous Output Current
  • 12A Peak Output Current
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 22mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 7mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-22A 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8742 is a 10A, synchronous, step-down converter with integrated 22mΩ N-channel High-Side MOSFET and 7mΩ Low-Side MOSFET. The APW8742 steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8742 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8742 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8742 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8742 has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8742 is available in TQFN4x4-22A (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8742S
Active
High Input Voltage PWM Converter With Low Iq

Features
  • Adjustable Output Voltage from +0.8V to +12V
- 0.8V Reference Voltage
- +1% Accuracy over Temperature
  • Operates from An Input Battery Voltage Range of +2.7V to +28V
  • 15A Peak Output Current
  • Power-On-Reset Monitoring on VCC pin
  • Excellent line and load transient responses
  • PFM mode for increased light load efficiency
  • Programmable PWM Frequency from 100kHz to 1000kHz
  • Integrated 18mΩ at VCC=5V N-Channel MOSFET For High Side
  • Integrated 5mΩ at VCC=5V N-Channel MOSFET For Low Side
  • Integrated Bootstrap Forward P-CH MOSFET
  • External Adjustable Soft-Start and Soft-Stop
  • Selectable Forced PWM or automatic PFM/PWM mode
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN-22A 4mmx4mm package
  • Lead Free and Green Device Available (RoHS Compliant)

General Description
The APW8742S is a synchronous, step-down converter with integrated 18mΩ N-channel High-Side MOSFET and 5mΩ Low-Side MOSFET. The APW8742S steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8742S provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8742S provides very high efficiency over light to heavy loads with loadingmodulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8742S is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for various applications. A Power-On-Reset function monitors the voltage on VCC to prevent wrong operation during power-on. The APW8742S has external adjustable soft-start and built-in an integrated output discharge method for soft stop. A soft-start ramps up the output voltage with programmable timing to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8742S is available in TQFN4x4-22A (Power PAK).
檔案下載+ 加入洽詢+ 加入比較 +
APW8743
Active
HV Dual Channels POL for Intel TGL VNN & V1P05A

Features
  • Support wide input voltage range from 5.0V to 22V
  • 1 high efficiency COT Mode with 0.5A output current capability for VNN_BYP
  • 1 high efficiency COT Mode with 0.5A output current capability for V1P05A_BYP
  • Fixed 500KHz Switching Frequency for each channel
  • Automatic switch over PWM/PFM Control
  • Stable with low ESR Ceramic output capacitors
  • Built VIN and VCC POR Control
  • Built in Current Limit Protection with Latch off Mode
  • Built in Under Voltage Protection with Latch off Mode
  • Built in Over Voltage Protection with Latch off Mode
  • Built in Over Temperature Protection
  • Built in Individual EN Control for VNN_BYP & V1P05A_BYP
  • Built in One POK signal indicator for VNN_BYP & V1P05A_BYP
  • Built in Individual VID Control for VNN_BYP & V1P05A_BYP
  • TQFN 3x3-16B package

General Description
The APW8743/A/B is a HV Dual Channels switching converter designed to provide supply voltages for Intel Tiger Lake (TGL)* VNN and V1P05A application. The device is specially designed to provide high efficiency at lighter loads in the range of 4 to 50mA as the application requires while providing peak currents of up to 500mA. The APW8743/A/B is equipped with an automatic PFM/ PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for low-noise requirements. The converter is also equipped with some practical protections include over-temperature (OTP), over-voltage (OVP), under-voltage (UVP) and accurate over-current protections (OCP) for various applications. The poweronreset function and soft-start used to prevent wrong operation and limit the input surge current during poweron or start-up. A softstop function actively discharges the output capacitors by built-in integrated output discharge method. This device, available TQFN 3x3-16B for APW8743/A/B, provides a very compact system solution external components and PCB area.
(*) Tiger Lake is trade mark of Intel Corp.
檔案下載+ 加入洽詢+ 加入比較 +
APW8743C/D/E
Active
HV Dual Channels POL for Intel TGL VNN & V1P05A

Features
  • Support wide input voltage range from 4.5V to 24V
  • 1 high efficiency COT Mode with 0.5A output current capability for VNN_BYP
  • 1 high efficiency COT Mode with 0.5A output current capability for V1P05A_BYP
  • Fixed 500KHz Switching Frequency for each channel
  • Automatic switch over PWM/PFM Control
  • Stable with low ESR Ceramic output capacitors
  • Built VIN and VCC POR Control
  • Built in Current Limit Protection with Latch off Mode
  • Built in Under Voltage Protection with Latch off Mode
  • Built in Over Voltage Protection with Latch off Mode
  • Built in Over Temperature Protection
  • Built in Individual EN Control for VNN_BYP & V1P05A_BYP
  • Built in One POK signal indicator for VNN_BYP & V1P05A_BYP
  • Built in Individual VID Control for VNN_BYP & V1P05A_BYP
  • TQFN 3x3-16B package

General Description
The APW8743C/D/E is a HV Dual Channels switching converter designed to provide supply voltages for Intel Tiger Lake (TGL)* VNN and V1P05A application. The device is specially designed to provide high efficiency at lighter loads in the range of 4 to 50mA as the application requires while providing peak currents of up to 500mA. The APW8743C/D/E is equipped with an automatic PFM/ PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for low-noise requirements. The converter is also equipped with some practical protections include over-temperature (OTP), over-voltage (OVP), under-voltage (UVP) and accurate over-current protections (OCP) for various applications. The poweronreset function and soft-start used to prevent wrong operation and limit the input surge current during poweron or start-up. A softstop function actively discharges the output capacitors by built-in integrated output discharge method. This device, available TQFN 3x3-16B for APW8743C/D/E, provides a very compact system solution external components and PCB area.
(*) Tiger Lake is trade mark of Intel Corp.
檔案下載+ 加入洽詢+ 加入比較 +
APW8765B
Active
High Input Voltage 3.3V / 6A & 5V / 6A Synchronous Buck Converter with 100mA LDO

Features
  • Wide Operating Range from +5.5V to +23V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.2V ~ 4.4V range
  • Built-in 100uA low quiescent current
  • Support IOUT=6A Application
  • Built in PWM & PFM Control Schemes with COT architecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • APW8765B Fixed Switching Frequency from 500KHz
  • APW8765C Fixed Switching Frequency from 750KHz
  • APW8765B Fixed 3.3V VOUT REF voltage with ±0.6% accuracy
  • APW8765C Fixed 5.1V VOUT REF voltage with ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 1.65mS
  • Integrated 30mΩ N-Channel MOSFET For High Side MOS
  • Integrated 15mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • Built in 3.3V & 5.0V / 100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70% of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET Rds(on) and low-side MOSFET Rds(on) sensing
  • Flip-Chip VTQFN 3x3-12P with Lead Free & RoHS compliant

General Description
The APW8765B/C is a 6A, synchronous buck converter with integrated 30mΩ High-Side MOSFET and 15mΩ Low-Side MOSFET. The APW8765B/C designed with a constant on-time control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8765B/C is equipped with an automatic PFM/ PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for low-noise requirements. The APW8765B/C is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, over-current and currentlimit) into a single package. This device, available in VTQFN 3x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8765C
Active
High Input Voltage 3.3V / 6A & 5V / 6A Synchronous Buck Converter with 100mA LDO

Features
  • Wide Operating Range from +5.5V to +23V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.2V ~ 4.4V range
  • Built-in 100uA low quiescent current
  • Support IOUT=6A Application
  • Built in PWM & PFM Control Schemes with COT architecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • APW8765B Fixed Switching Frequency from 500KHz
  • APW8765C Fixed Switching Frequency from 750KHz
  • APW8765B Fixed 3.3V VOUT REF voltage with ±0.6% accuracy
  • APW8765C Fixed 5.1V VOUT REF voltage with ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 1.65mS
  • Integrated 30mΩ N-Channel MOSFET For High Side MOS
  • Integrated 15mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • Built in 3.3V & 5.0V / 100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70% of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET Rds(on) and low-side MOSFET Rds(on) sensing
  • Flip-Chip VTQFN 3x3-12P with Lead Free & RoHS compliant

General Description
The APW8765B/C is a 6A, synchronous buck converter with integrated 30mΩ High-Side MOSFET and 15mΩ Low-Side MOSFET. The APW8765B/C designed with a constant on-time control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8765B/C is equipped with an automatic PFM/ PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for low-noise requirements. The APW8765B/C is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, over-current and currentlimit) into a single package. This device, available in VTQFN 3x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8802
Active
High Input Voltage 8A PWM DC/DC Converter

Features
  • Operates from An Input Battery Voltage Range of +3V to +25V
  • ±1.6% 0.75V Reference
- Over Line, Load Regulation, and Operating Temp.
  • High Efficiency all Over 90% at VOUT=1V, VIN=19V Condition
  • Power-On-Reset Monitoring on PVCC and VCC Pins
  • Excellent Line and Load Transient Responses
  • Integrated 12mΩ @ VCC=5V N-Channel MOSFET For High Side
  • Integrated 12mΩ @ VCC=5V N-Channel MOSFET For Low Side
  • Programmable PWM Frequency from 100kHz to 500kHz
  • Built-in 1.2ms Digital Soft-Start & Soft-Stop
  • Built-in COT Mode Control for Fast Response and MLCC Supports
  • Power Good Monitoring
  • 70% Under-Voltage Protection
  • 125% Over-Voltage Protection
  • Adjustable Current-Limit Protection
- Using Built-in Low-Side MOSFET’s RDS(ON)
  • Over-Temperature Protection
  • TQFN5x6-28 (Power PAK) Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW8802 is a 8A, synchronous, step-down converter with integrated 12mΩ N-channel High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8802 steps down high voltage to generate low-voltage chipset or RAM supplies in notebook computers. The APW8802 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8802 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. In PWM Mode, the converter works nearly at constant frequency for low-noise requirements. The APW8802 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections, perfect for NB applications. A Power-On-Reset function monitors the voltage on VPVCC and VCC to prevent wrong operation during power-on. The APW8802 has a 1.2ms digital soft-start and built-in an integrated output discharge device for soft-stop. An internal integrated soft-start ramps up the output voltage with programmable slew rate to reduce the start-up current. A soft-stop function actively discharges the output capacitors. The APW8802 is available in TQFN5x6-28 (Power PAK) package.
檔案下載+ 加入洽詢+ 加入比較 +
APW8804
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic PFM/PWM Mode Operation
  • Adjustable Output Voltage from 0.6V to VPVDD
  • Integrated 65mΩ High Side / 55mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VDD and PVDD
  • Integrated Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High/ Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • Small TDFN3x3-10 and SOP-8P Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8804 is a 3A synchronous buck converter with integrated 65mΩ high side and 55mΩ low side power MOSFETs. The APW8804, design with a current-mode control scheme, can convert wide input voltage of 2.6V to 6V to the output voltage adjustable from 0.6V to 6V to provide excellent output voltage regulation. The APW8804 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. At PWM mode, the switching frequency is set by the external resistor. The APW8804 is also equipped with Power-on-reset, softstart, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10 and SOP-8P, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8804E
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic PFM/PWM Mode Operation
  • Adjustable Output Voltage from 0.6V to VPVDD
  • Integrated 65mΩ High Side / 55mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VDD and PVDD
  • Integrated Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/ShutdownFunction
  • TDFN3x3-10 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8804E is a 3A synchronous buck converter with integrated 65mΩ high side and 55mΩ low side power MOSFETs. The APW8804E, design with a current-mode control scheme, can convert wide input voltage of 2.6V to 5.5V to the output voltage adjustable from 0.6V to 5.5V to provide excellent output voltage regulation. The APW8804E is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. At PWM mode, the switching frequency is set by the external resistor. The APW8804E is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8805
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
  • Adjustable Output Voltage from 0.8V to VVIN
  • Integrated 75mΩ High Side / 55mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Mode Selection
- APW8805: PFM/PWM mode
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VCC and VIN
  • Integrated Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/ShutdownFunction
  • Current-M ode Operation with Internal Compensation
  • Small TDFN3x3-10 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8805 is a 3A synchronous buck converter with integrated 75mΩ high side and 55mΩ low side power MOSFETs. The APW8805, design with a current-mode control scheme, can convert wide input voltage of 2.6V to 6V to the output voltage adjustable from 0.8V to 6V to provide excellent output voltage regulation. The APW8805 is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. At PWM mode, the switching frequency is set by the external resistor. The APW8805 is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8805A
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
  • Adjustable Output Voltage from 0.8V to VVIN
  • Integrated 75mΩ High Side / 55mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Mode Selection
- APW8805A: Force PWM
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VCC and VIN
  • Integrated Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable / Shutdown Function
  • Current-Mode Operation with Internal Compensation
  • Small TDFN3x3-10 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8805A is a 3A synchronous buck converter with integrated 75mΩ high side and 55mΩ low side power MOSFETs. The APW8805A, design with a current-mode control scheme, can convert wide input voltage of 2.6V to 6V to the output voltage adjustable from 0.8V to 6V to provide excellent output voltage regulation. The APW8805A is equipped with force PWM mode opeation. The APW8805A is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8805B
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
  • Adjustable Output Voltage from 0.6V to VVIN
  • Integrated 75mΩ High Side / 55mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty Cycle
  • Mode Selection
- APW8805B: PFM/PWM mode
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VCC and VIN
  • Integrated Soft-Start and Soft-Stop and Pre-bias Startup
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable / Shutdown Function
  • Current-Mode Operation with Internal Compensation
  • Small TDFN3x3-10 Packages
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8805B is a 3A synchronous buck converter with integrated 75mΩ high side and 55mΩ low side power MOSFETs. The APW8805B, design with a current-mode control scheme, can convert wide input voltage of 2.6V to 6V to the output voltage adjustable from 0.6V to 6V to provide excellent output voltage regulation. The APW8805B is equipped with an automatic PFM/PWM mode operation. At light load, the IC operates in the PFM mode to reduce the switching losses. At heavy load, the IC works in PWM mode. At PWM mode, the switching frequency is set by the external resistor. The APW8805B is also equipped with Power-on-reset, soft-start, soft-stop, Pre-bias startup and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8824
Active
1.5MHz, 1A Synchronous Buck Regulator

Features
  • 1A Output Current
  • Wide 2.7V ~ 5.5V Input Voltage
  • Fixed 1.5MHz Switching Frequency
  • Low Dropout Operating at 100% duty cycle
  • Low 25µA Quiescent Current
  • Integrate Synchronous Rectifier
  • 0.6V Low Reference Voltage
  • <0.5µA Input Current during Shutdown
  • Current-Mode Operation with Internal Compensation
- Stable with Ceramic Output Capacitors
- Fast Line Transient Response
  • Over-Voltage Protection
  • Under Voltage Protection
  • Over-Temperature Protection with Hysteresis
  • Available in a TSOT-23-6A Package
  • Halogen and Lead Free Available (RoHS Compliant)

General Description
The APW8824 is a high efficiency monolithic synchronous buck regulator. APW8824 operates with a constant 1.5MHz switching frequency and using the inductor current as a controlled quantity in the current mode architecture. The 2.7V to 5.5V input voltage range makes the APW8824 ideally suited for single Li-Ion battery powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable electrical devices. The internally fixed 1.5MHz operating frequency allows the use of small surface mount inductors and capacitors. The synchronous switches included inside increase the efficiency and eliminate the need for an external Schottky diode. The APW8824 is available in TSOT-23-6A package.
檔案下載+ 加入洽詢+ 加入比較 +
APW8825
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Adjustable Output Voltage from 0.6V to VIN
  • Integrated 110mΩ High side / 80mΩ Low Side MOSFETs
  • Low Dropout Operation: 100% Duty cycle
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrate Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/ShutdownFunction
  • Small SOT-23-6, TDFN2x2-8 and VTDFN2x2-8 packages
  • Lead Free and Green Devices Available (RoHS compliant)

General Description
APW8825 is a 3A synchronous buck converter with integrated 110mΩ high side and 80mΩ low side power MOSFETs. The APW8825 design with a current-mode control scheme, can convert wide input voltage of 2.6V to 5.5V to the output voltage adjustable from 0.6V to 5.5V to provide excellent output voltage regulation. The APW8825 is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. At PWM mode, the switching frequency is set by the external resistor. The APW8825 is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN2x2-8, VTDFN2x2-8 and SOT-23-6 provide a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8827
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Integrated 75mΩ High side / 65mΩ Low Side MOSFETs
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrate Soft-Start and Output Discharge
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • Small SOT-23-6, TDFN2x2-8 and VTDFN2x2-8 packages
  • Lead Free and Green Devices Available (RoHS compliant)

General Description
APW8827 is a 3A synchronous buck converter with integrated 75mΩ high side and 65mΩ low side power MOSFETs. The APW8827 design with a current-mode control scheme, can convert wide input voltage of 2.9V to 5.5V to provide excellent output voltage regulation. The APW8827 is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW8827 is also equipped with Power-on-reset, soft-start, Output Discharge, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN2x2-8, VTDFN2x2-8 and SOT-23-6 provide a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8827A
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Integrated 75mΩ High side / 65mΩ Low Side MOSFETs
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrate Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • Small SOT-23-6, SOT-23-5, and TDFN2x2-8 packages
  • Lead Free and Green Devices Available (RoHS compliant)

General Description
APW8827A is a 3A synchronous buck converter with integrated 75mΩ high side and 65mΩ low side power MOSFETs. The APW8827A design with a current-mode control scheme, can convert wide input voltage of 2.9V to 5.5V to provide excellent output voltage regulation. The APW8827A is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW8827A is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN2X2-8, SOT-23-5 and SOT-23-6 provide a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8827B
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Effi ciency up to 95%
- Automatic Skip/PWM Mode Operation
  • Adjustable Output Voltage from 0.6V to VIN
  • Integrated 75mΩ High side / 65mΩ Low Side MOSFETs
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrate Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High Side Current Limit
  • Power Good Indication
  • Enable/ShutdownFunction
  • Small TDFN2x2-8, SOT-23-6 packages
  • Lead Free and Green Devices Available (RoHS compliant)

General Description
APW8827B is a 3A synchronous buck converter with integrated 75mΩ high side and 65mΩ low side power MOSFETs. The APW8827B design with a current-mode control scheme, can convert wide input voltage of 2.9V to 5.5V to provide excellent output voltage regulation. The APW8827B is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW8827B is also equipped with Power-on-reset, soft-start and whole protections (under-voltage, overvoltage, over-temperature and current-limit) into a single package. This device is available in TDFN2x2-8, SOT-23-6 provide a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8827D
Active
3A 5V 800kHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Integrated 75mΩ High side / 65mΩ Low Side MOSFETs
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrate Soft-Start and Output Discharge
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • Small TDFN2x2-8 and SOT-23-6 Packages

General Description
APW8827D is a 3A synchronous buck converter with integrated 75mΩ high side and 65mΩ low side power MOSFETs. The APW8827D design with a current-mode control scheme, can convert wide input voltage of 2.9V to 5.5V to provide excellent output voltage regulation. The APW8827D is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW8827D is also equipped with Power-on-reset, soft-start, Output Discharge, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available in TDFN2x2-8 and SOT-23-6 packages, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8830
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Integrated 75mΩ High Side / 65mΩ Low Side MOSFETs
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VDD and PVDD
  • Integrated Soft-Start and Soft-Stop
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • TDFN3x3-10 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8830 is a 3A synchronous buck converter with integrated 75mΩ high side and 65mΩ low side power MOSFETs. The APW8830, design with a current-mode control scheme, can convert wide input voltage of 2.9V to 5.5V to provide excellent output voltage regulation. The APW8830 is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW8830 is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8830A
Active
3A 5V 1MHz Synchronous Buck Converter

Features
  • High Efficiency up to 95%
- Automatic Skip/PWM Mode Operation
  • Integrated 75mΩ High Side / 65mΩ Low Side MOSFETs
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VDD
  • Integrated Soft-Start
  • Over-Temperature Protection
  • Over-Voltage Protection
  • Under-Voltage Protection
  • High / Low Side Current Limit
  • Power Good Indication
  • Enable/Shutdown Function
  • TDFN3x3-10 Package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
APW8830A is a 3A synchronous buck converter with integrated 75mΩ high side and 65mΩ low side power MOSFETs. The APW8830A, design with a current-mode control scheme, can convert wide input voltage of 2.9V to 5.5V to provide excellent output voltage regulation. The APW8830A is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW8830A is also equipped with Power-on-reset, soft-start, and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10, provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8835
Active
24V, 3A DC-DC Synchronous Buck Converter

Features
  • Wide Input Voltage Range from 7.5V to 24V
  • 3A Continuous Output Current
  • Adjustable Output Voltage from 0.8V to 20V
  • VREF=0.8V ±1% over all Load & Line Regulation & TC Range
  • Integrated High/Low Side MOSFET
  • High Efficiency Performance up to 95% scale
  • Low Shutdown Current <1µA scale
  • Built-in Internal 1.5ms Soft-Start & Soft-Stop Functions
  • Fixed 600kHz Switching Frequency with Maximum 90% Duty
  • Force PWM Mode Operation
  • Built-in Current Mode Control for Fast Response & MLCC supports with Internal
  • Stable with Low ESR Capacitors
  • Power-On-Reset Detection on VCC & VIN
  • Over-Temperature Protection
  • Over Voltage Protection
  • Current-Limit Protection with Frequency Foldback
  • Enable/Shutdown Function
  • Current-Mode Operation with Internal Compensation
  • Small TDFN3x3-10 packages
  • Lead Free and Green Devices Available (RoHS compliant)

General Description
APW8835 is a 3A synchronous buck converter with integrated power MOSFETs. The APW8835 design with a current-mode control scheme, can convert wide input voltage of 7.5V to 24V to the output voltage adjustable from 0.8V to 20V to provide excellent output voltage regulation. The APW8835 is equipped with force PWM mode operation. The APW8835 is also equipped with Power-on-reset, soft-start and whole protections (under-voltage, over-voltage, over-temperature and current-limit) into a single package. This device, available TDFN3x3-10 provides a very compact system solution external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8861
Active
DDR3 AND DDR4 SYNCHRONOUS BUCK CONTVERTER WITH 1.5A LDO

Features
Buck Controller (VDDQ)
  • High Input Voltages Range from 4.5V to 26V Input Power
  • Provide Adjustable Output Voltage from 0.75V to 3.3V
  • Integrated MOSFET Drivers and Bootstrap Forward P-CH MOSFET
  • Low Quiescent Current (200uA)
  • Excellent Load Transient Responses
  • PFM Mode for Increased Light Load Efficiency
  • Constant On-Time Controller Scheme
- Switching Frequency Compensation for PWM Mode
- Adjustable Switching Frequency from 400kHz to 550kHz in PWM Mode with DC Output Current
  • S3 and S5 Pins Control The Device in S0, S3 or S4/ S5 State
  • Power Good Monitoring
  • 70% Under-Voltage Protection (UVP)
  • 125% Over-Voltage Protection (OVP)
  • Adjustable Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • TQFN-32 4mmx4mm Thin package
  • Lead Free Available (RoHS Compliant) ±1.5A LDO Section (VTT)
  • Sourcing and Sinking Current up to 1.5A
  • Fast Transient Response for Output Voltage
  • Output Ceramic Capacitors Support at least 10µF MLCC
  • VTT and VTTREF Track at Half the VDDQSNS by internal divider
  • ±20mV Accuracy for VTT and VTTREF
  • Independent Over-Current Limit (OCL)
  • Thermal Shutdown Protection

General Description
The APW8861 integrates a synchronous buck PWM converter to generate VDDQ, a sourcing and sinking LDO linear regulator to generate VTT. It offers the lowest total solution cost in system where space is at a premium. The APW8861 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8861 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. On TQFN-32 Package, the Forced PWM Mode works nearly at constant frequency for low-noise requirements. The APW8861 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections. A Power-On-Reset function monitors the voltage on VCC prevents wrong operation during power on. The LDO is designed to provide a regulated voltage with bi-directional output current for DDR-SDRAM termination. The device integrates two power transistors to source and sink current up to 1.5A. It also incorporates current-limit and thermal shutdown protection. The output voltage of LDO tracks the voltage at VREF pin. An internal resistor divider is used to provide a half voltage of VREF for VTTREF and VTT Voltage. The VTT output voltage is only requiring 20µF of ceramic output capacitance for stability and fast transient response. The S3 and S5 pins provide the sleep state for VTT (S3 state) and suspend state (S4/S5 state) for device, when S5 and S3 are both pulled low the device provides the soft-off for VTT and VTTREF.
檔案下載+ 加入洽詢+ 加入比較 +
APW8863
Active
DDR3 AND DDR4 SYNCHRONOUS BUCK CONTVERTER WITH 1.5A LDO

Features
Buck Controller (VDDQ)
  • High Input Voltages Range from 4.5V to 21V Input Power
  • Provide Adjustable Output Voltage from 0.9V to 2V
  • Integrated MOSFET Drivers and Bootstrap Forward P-CH MOSFET
  • Low Quiescent Current (200uA)
  • Excellent Load Transient Responses
  • PFM Mode for Increased Light Load Efficiency
  • Constant On-Time Controller Scheme
- Switching Frequency Compensation for PWM Mode
- Adjustable Switching Frequency from 400kHz to 550kHz in PWM Mode with DC Output Current
  • S3 and S5 Pins Control The Device in S0, S3 or S4/ S5 State
  • Power Good Monitoring
  • 70% Under-Voltage Protection (UVP)
  • 125% Over-Voltage Protection (OVP)
  • Adjustable Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • TQFN-32 4mmx4mm Thin package
  • Lead Free Available (RoHS Compliant)
  • ±1.5A LDO Section (VTT)
  • Souring or Sinking Current up to 1.5A
  • Fast Transient Response for Output Voltage
  • Output Ceramic Capacitors Support at least 10µF MLCC
  • VTT and VTTREF Track at Half the VDDQSNS by internal divider
  • ±20mV Accuracy for VTT and VTTREF
  • Independent Over-Current Limit (OCL)
  • Thermal Shutdown Protection

General Description
The APW8863 integrates a synchronous buck PWM converter to generate VDDQ, a sourcing and sinking LDO linear regulator to generate VTT. It offers the lowest total solution cost in system where space is at a premium. The APW8863 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8863 provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. On TQFN-32 Package, the Forced PWM Mode works nearly at constant frequency for low-noise requirements. The APW8863 is equipped with accurate current-limit, output under-voltage, and output over-voltage protections. A Power-On-Reset function monitors the voltage on VCC prevents wrong operation during power on. The LDO is designed to provide a regulated voltage with bi-directional output current for DDR-SDRAM termination. The device integrates two power transistors to source or sink current up to 1.5A. It also incorporates current-limit and thermal shutdown protection. The output voltage of LDO tracks the voltage at VREF pin. An internal resistor divider is used to provide a half voltage of VREF for VTTREF and VTT Voltage. The VTT output voltage is only requiring 20µF of ceramic output capacitance for stability and fast transient response. The S3 and S5 pins provide the sleep state for VTT (S3 state) and suspend state (S4/S5 state) for device, when S5 and S3 are both pulled low the device provides the soft-off for VTT and VTTREF.
檔案下載+ 加入洽詢+ 加入比較 +
APW8863A
Active
DDR3 AND DDR4 SYNCHRONOUS BUCK CONTVERTER WITH 1.5A LDO

Features
Buck Controller (VDDQ)
  • High Input Voltages Range from 4.5V to 21V Input Power
  • Provide Adjustable Output Voltage from 0.9V to 2V
  • Integrated MOSFET Drivers and Bootstrap Forward P-CH MOSFET
  • Low Quiescent Current (200uA)
  • Excellent Load Transient Responses
  • PFM Mode for Increased Light Load Efficiency
  • Constant On-Time Controller Scheme
- Switching Frequency Compensation for PWM Mode
- Adjustable Switching Frequency from 400kHz to 550kHz in PWM Mode with DC Output Current
  • S3 and S5 Pins Control The Device in S0, S3 or S4/ S5 State
  • Power Good Monitoring
  • 70% Under-Voltage Protection (UVP)
  • 125% Over-Voltage Protection (OVP)
  • Adjustable Current-Limit Protection
- Using Sense Low-Side MOSFET’s RDS(ON)
  • TQFN-32 4mmx4mm Thin package
  • Lead Free Available (RoHS Compliant) ±1.5A LDO Section (VTT)
  • Souring or Sinking Current up to 1.5A
  • Fast Transient Response for Output Voltage
  • Output Ceramic Capacitors Support at least 10µF MLCC
  • VTT and VTTREF Track at Half the VDDQSNS by internal divider
  • ±20mV Accuracy for VTT and VTTREF
  • Independent Over-Current Limit (OCL)
  • Thermal Shutdown Protection

General Description
The APW8863A integrates a synchronous buck PWM converter to generate VDDQ, a sourcing and sinking LDO linear regulator to generate VTT. It offers the lowest total solution cost in system where space is at a premium. The APW8863A provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8863A provides very high efficiency over light to heavy loads with loadingmodulated switching frequencies. On TQFN-32 Package, the Forced PWM Mode works nearly at constant frequency for low-noise requirements. The APW8863A is equipped with accurate current-limit, output under-voltage, and output over-voltage protections. A Power-On-Reset function monitors the voltage on VCC prevents wrong operation during power on. The LDO is designed to provide a regulated voltage with bi-directional output current for DDR-SDRAM termination. The device integrates two power transistors to source or sink current up to 1.5A. It also incorporates current-limit and thermal shutdown protection. The output voltage of LDO tracks the voltage at VREF pin. An internal resistor divider is used to provide a half voltage of VREF for VTTREF and VTT Voltage. The VTT output voltage is only requiring 20µF of ceramic output capacitance for stability and fast transient response. The S3 and S5 pins provide the sleep state for VTT (S3 state) and suspend state (S4/S5 state) for device, when S5 and S3 are both pulled low the device provides the soft-off for VTT and VTTREF.
檔案下載+ 加入洽詢+ 加入比較 +
APW8863D
Active
HV Buck PWM Converter For LPDDR5

Features
  • Wide Operating Range from 4.5V to 24V Input Voltages
  • Power-On-Reset Monitoring on VCC at 4.3V
  • Support Dual Output VDD2 (8A), VDDQ (1A)
  • Support Internal Power Sequency Control for Memory
  • Built in Auto-PFM / Shutdown Control Schemes by EN Pin
  • Built in DVFS Function by Mode Pin
  • Built in Fixed Soft Start / Internal Stop Control
  • Built in Over-Temperature Protection 160°C, hysteresis 25°C
  • TQFN 4x4-32p
HV 8A Buck Converter for VDD2
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • Built in Integrated MOSFET H/S RDS (ON) 15mΩ & L/S RDS (ON) 8mΩ
  • Selectable Switching Frequency by TON Pin
  • Built in Open-Drain-Type POK function for PWM output
  • UVP setting at 70% of VOUT & OVP setting at 125%
  • Built in Current limit Protection using Low-side MOS sensing by CS setup
LV 1A LDO for VDDQ
  • Support VDDQ 1A output current
  • Built in Individual Power On/Off Control by VDDQEN pin
  • Built in Internal Soft-Start and Output Discharge
  • Built in Current Limit Protection 1.5A (min.)

General Description
The APW8863D integrates a synchronous buck PWM converter to generate VDD2, a sourcing and sinking LDO linear regulator to generate VDDQ. It offers the lowest total solution cost in system where space is at a premium. The APW8863D provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Mode (PFM), the APW8863D provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. On TQFN-32 Package, the Forced PWM Mode works nearly at constant frequency for low-noise requirements. The APW8863D is equipped with accurate current-limit, output under-voltage, and output over-voltage protections. A Power-On-Reset function monitors the voltage on VCC prevents wrong operation during power on. The LDO is designed to provide a regulated voltage with bi-directional output current for DDR-SDRAM termination. The device integrates two power transistors to source and sink current up to 1A. It also incorporates current-limit and thermal shutdown protection. The output voltage of VDDQ (LDO) tracks the voltage at VDDQREF. The VDDQ output voltage is only requiring 20µF of ceramic output capacitance for stability and fast transient response. The VDDQEN and EN pins provide the sleep state for VDDQ (S3 state) and suspend state (S4/S5 state) for device, when EN and VDDQEN are both pulled low the device provides the soft-off for VDDQ.
檔案下載+ 加入洽詢+ 加入比較 +
APW8878
Active
High Input Voltage 5V / 8A Synchronous Buck Converter with 100mA LDO

Features
  • Wide Operating Range from +5.5V to +24V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.5V ~ 4.9V range
  • Built-in 100uA low quiescent current
  • Support IOUT=8A Application
  • Built in PWM & PFM Control Schemes with COT achitecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • Fixed Switching Frequency from 700KHz
  • Fixed 5V VOUT REF voltage with ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 2.4ms
  • Integrated 25mΩ N-Channel MOSFET For High Side MOS
  • Integrated 12mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • Built in 5V / 100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70% of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET RDS(on) and low-side MOSFET RDS(on) sensing
  • Flip-Chip TQFN 2x3-12P with Lead Free & RoHS compliant

General Description
The APW8878 is a 8A, synchronous buck converter with integrated 25mΩ High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8878 designed with a constant on-time control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8878 is equipped with an automatic PFM/PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for lownoise requirements. The APW8878 is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, over-current and current-limit) into a single package. This device, available in TQFN 2x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8878A
Active
High Input Voltage 5.1V / 8A Synchronous Buck Converter with 100mA LDO and LP# Vout Control

Features
  • Wide Operating Range from +5.5V to +24V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.5V ~ 4.9V range
  • Built-in 100uA low quiescent current
  • Support IOUT=8A Application
  • Built in PWM & PFM Control Schemes with COT architecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • Fixed Switching Frequency from 700KHz
  • Fixed 5.1V VOUT REF voltagewith ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 2.4ms
  • LP# Output Voltage Control
  • Integrated 25mΩ N-Channel MOSFET For High Side MOS
  • Integrated 12mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • Built in 5V / 100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70% of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET RDS(on) and low-side MOSFET RDS(on) sensing
  • Flip-Chip TQFN 2x3-12P with Lead Free & RoHS compliant

General Description
The APW8878A is a 8A, synchronous buck converter with integrated 25mΩ High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8878A designed with a constant on-time control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8878A is equipped with an automatic PFM/PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for lownoise requirements. The APW8878A is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, over-current and current-limit) into a single package. This device, available in TQFN 2x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8878B
Active
High Input Voltage 5.1V / 8A Synchronous Buck Converter with 100mA LDO

Features
  • Wide Operating Range from +5.5V to +24V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.5V ~ 4.9V range
  • Built-in 100uA low quiescent current
  • Support IOUT=8A Application
  • Built in PWM & PFM Control Schemes with COT achitecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • Fixed Switching Frequency from 700KHz
  • Fixed 5.1V VOUT REF voltage with ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 2.4ms
  • Integrated 25mΩ N-Channel MOSFET For High Side MOS
  • Integrated 12mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • Built in 5V / 100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70% of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET RDS(on) and low-side MOSFET RDS(on) sensing
  • Flip-Chip TQFN 2x3-12P with Lead Free & RoHS compliant

General Description
The APW8878B is a 8A, synchronous buck converter with integrated 25mΩ High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8878B designed with a constant ontime control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8878B is equipped with an automatic PFM/PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for lownoise requirements. The APW8878B is also equipped with Power-on-reset, soft-start, and whole protections (under-voltage, over-voltage, over-temperature, over-current and current-limit) into a single package. This device, available in TQFN 2x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8879
Active
High Input Voltage 3.33V / 8A Synchronous Buck Converter with 100mA LDO

Features
  • Wide Operating Range from +5.5V to +24V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.5V ~ 4.9V range
  • Built-in 100uA low quiescent current
  • Support IOUT=8A Application
  • Built in PWM & PFM Control Schemes with COT architecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • Fixed Switching Frequency from 700KHz
  • Fixed 3.33V VOUT REF voltage with ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 2.4mS
  • Integrated 25mΩ N-Channel MOSFET For High Side MOS
  • Integrated 12mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • 250kHz CLK for External Charge Pump
  • Built in 3.3V/100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70% of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET RDS(on) and low-side MOSFET RDS(on) sensing
  • Flip-Chip TQFN 2x3-12P with Lead Free & RoHS compliant

General Description
The APW8879 is a 8A, synchronous buck converter with integrated 25mΩ High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8879 designed with a constant on-time control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8879 is equipped with an automatic PFM/PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for lownoise requirements. The APW8879 is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, over-current and current-limit) into a single package. The charge pump circuit with 250kHz clock driver uses VOUT as its power supply to generate approximately 10~12V DC voltage. This device, available in TQFN 2x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8879A
Active
High Input Voltage 3.36V / 8A Synchronous Buck Converter with 100mA LDO

Features
  • Wide Operating Range from +5.5V to +24V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.5V ~ 4.9V range
  • Built-in 100uA low quiescent current
  • Support IOUT=8A Application
  • Built in PWM & PFM Control Schemes with COT achitecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • Fixed Switching Frequency from 700KHz
  • Fixed 3.36V VOUT REF voltage with ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 2.4ms
  • Integrated 25mΩ N-Channel MOSFET For High Side MOS
  • Integrated 12mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • Built in 3.36V / 100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70%of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET RDS(on) and low-side MOSFET RDS(on) sensing
  • Flip-Chip TQFN 2x3-12P with Lead Free & RoHS compliant

General Description
The APW8879A is a 8A, synchronous buck converter with integrated 25mΩ High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8879A designed with a constant on-time control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8879A is equipped with an automatic PFM/PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for lownoise requirements. The APW8879A is also equipped with Power-on-reset, soft-start, soft-stop, and whole protections (under-voltage, over-voltage, over-temperature, over-current and current-limit) into a single package. The charge pump circuit with 250kHz clock driver uses VOUT as its power supply to generate approximately 10~12V DC voltage. This device, available in TQFN 2x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW8879B
Active
High Input Voltage 3.33V / 8A Synchronous Buck Converter with 100mA LDO

Features
  • Wide Operating Range from +5.5V to +24V Input Voltages
  • Power-On-Reset Monitoring on VIN at 4.5V ~ 4.9V range
  • Built-in 100uA low quiescent current
  • Support IOUT=8A Application
  • Built in PWM & PFM Control Schemes with COT achitecture
  • Built in Integrated Bootstrap Forward P-CH MOSFET
  • Fixed Switching Frequency from 700KHz
  • Fixed 3.33V VOUT REF voltage with ±0.6% accuracy
  • Support Ultrasonic Mode selection on EN Pin
  • Support built-in fixed Soft Start time 2.4ms
  • Integrated 25mΩ N-Channel MOSFET For High Side MOS
  • Integrated 12mΩ N-Channel MOSFET For Low Side MOS
  • Built in Open-Drain Type POK function and EN control
  • Built in 3.3V / 100mA LDO and Switch-over MOSFET with PWM output
  • UVP setting at 70% of VREF & OVP setting at 125% of VREF & Thermal Shutdown
  • Built in Over Current Protection and Current Limit Protection using high-side MOSFET RDS(on) and low-side MOSFET RDS(on) sensing
  • Flip-Chip TQFN 2x3-12P with Lead Free & RoHS compliant

General Description
The APW8879B is a 8A, synchronous buck converter with integrated 25mΩ High-Side MOSFET and 12mΩ Low-Side MOSFET. The APW8879B designed with a constant ontime control architecture can step down high voltage to accommodate low-voltage chipset for IMPV8 applications. The APW8879B is equipped with an automatic PFM/PWM mode operation. At light load, the converter operates in the PFM mode to reduce the switching losses and provide high efficiency. At heavy load, the converter works in PWM mode and operates nearly at constant frequency for lownoise requirements. The APW8879B is also equipped with Power-on-reset, soft-start, and whole protections (under-voltage, over-voltage, over-temperature, over-current and current-limit) into a single package. The charge pump circuit with 250kHz clock driver uses VOUT as its power supply to generate approximately 10~12V DC voltage. This device, available in TQFN 2x3-12 package, provides a very compact system solution to minimize external components and PCB area.
檔案下載+ 加入洽詢+ 加入比較 +
APW9103
Active
3A, 18V, 600kHz Synchronous Step-Down Converter

Features
  • Input Voltage range: 4.5V to 18V
  • 3A Output Current
  • Typical 0.6V ±1% Internal Reference Voltage
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency :
- N-CH MOSFET (70mΩ) for High Side
- N-CH MOSFET (38mΩ) for Low Side
  • DyncBandwidthTM Technology
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TSOT-23-8 package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW9103 is a high efficiency synchronous buck converter with integrated 70mΩ/38mΩ of upper/lower power MOSFET and offers 3A continuous current capability. The APW9103 uses a peak current mode control scheme to regulate the output voltage. The internal switching frequency is set at 600kHz. And EN/SYNC supports external clock synchronization. The APW9103 is also equipped with Power-on-reset, soft- start, and whole protections (over-temperature, overvoltage, under-voltage, over-current) into a single package. The APW9103 is offered in a TSOT-23-8 package allowing small size while having an excellent thermal capability for power dissipation.
檔案下載+ 加入洽詢+ 加入比較 +
APW9105
Active
6A, 18V, 600kHz Synchronous Step-Down Converter

Features
  • Input Voltage range: 4.5V to 18V
  • 6A Output Current
  • ANPEC System Phase Shift (ASP) function Reduces System Noise by Daisy Chaining Converter with Phase Shift
  • Typical 0.6V ±1% Internal Reference Voltage
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET: 40mΩ for High Side
- N-CH MOSFET: 20mΩ for Low Side
  • VDD Bypass Function allows for External 5V supply
  • Mode Pin allows for Forced PWM or Automatic PSM/PWM mode
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TQFN3x2-14 package
  • Lead Free and Green Devices Available (RoHS Compliant)
  • DyncBandwidthTM Technology
  • SpeedTransTM Technology

General Description
The APW9105 is a high efficiency synchronous buck converter with integrated 40m/20mΩ of upper/lower power MOSFET and offers 6A continuous current capability. This part is part of the family of converters with a proprietary ANPEC System Phase Shift (ASP) method that allows multiple converters to be daisy chained together while being able to synchronize to an external clock, allowing for a much reduced system noise performance. The ASP pin of the APW9105 can output a synchronized clock to the external clock with a slight phase delay to the next converter such that next converter will not turn on at the same time. Another feature of this part is its ability to automatically optimize its BW (DyncBandwidth) to allow better dynamic response once it is synchronized to a higher external clock. The APW9105 uses a peak current mode control scheme to regulate the output voltage. The internal switching frequency is set at 600kHz while the EN/SYNC pin supports external clock synchronization. The APW9105 also equips a technique: SpeedTransTM, which allows improving transient response without complex external compensation circuits design. VDD bypass pin allows for an external 5V supply to power the internal control circuitry thereby reducing overall system power consumption for better efficiency especially at light load conditions. And PM selection, It can improve the efficiency when the load is light. The APW9105 is also equipped with Power-on-reset, soft-start, and complete protections, over-temperature, overvoltage, under-voltage and over-current of the converter The APW9105 is offered in a TQFN3x2-14 package allowing small size while having an excellent thermal capability for power dissipation.
檔案下載+ 加入洽詢+ 加入比較 +
APW9106
Active
10A, 18V, 600kHz Synchronous Step-Down Converter

Features
  • Input Voltage range: 4.5V to 18V
  • 10A Output Current
  • ANPEC System Phase Shift (ASP) function Reduces System Noise by Daisy Chaining Converter with Phase Shift
  • Typical 0.6V ±1% Internal Reference Voltage
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET: 20mΩ for High Side
- N-CH MOSFET: 11mΩ for Low Side
  • VDD Bypass Function allows for External 5V supply
  • Mode Pin allows for Forced PWM or Automatic PSM/PWM mode
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TQFN3x3-14 package
  • Lead Free and Green Devices Available (RoHS Compliant)
  • SpeedTransTM Technology

General Description
The APW9106 is a high efficiency synchronous buck converter with integrated 20m/11mΩ of upper/lower power MOSFET and offers 10A continuous current capability. This part is part of the family of converters with a proprietary ANPEC System Phase Shift (ASP) method that allows multiple converters to be daisy chained together while being able to synchronize to an external clock, allowing for a much reduced system noise performance. The ASP pin of the APW9106 can output a synchronized clock to the external clock with a slight phase delay to the next converter such that next converter will not turn on at the same time. The APW9106 uses a peak current mode control scheme to regulate the output voltage. The internal switching frequency is set at 600kHz while the EN/SYNC pin supports external clock synchronization. The APW9106 also equips a technique: SpeedTransTM, which allows improving transient response without complex external compensation circuits design. VDD bypass pin allows for an external 5V supply to power the internal control circuitry thereby reducing overall system power consumption for better efficiency especially at light load conditions. And PM selection, It can improve the efficiency when the load is light. The APW9106 is also equipped with Power-on-reset, soft-start, and complete protections, over-temperature, overvoltage, under-voltage and over-current of the converter The APW9106 is offered in a TQFN3x3-14 package allowing small size while having an excellent thermal capability for power dissipation.
檔案下載+ 加入洽詢+ 加入比較 +
APW9109
Active
3A, 5V Input, 1MHz Synchronous Buck Converter

Features
  • Output Voltage can be as low as 0.3V
  • Automatic Skip/PWM Mode Operation
  • Force PWM Mode Operation
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrated Soft-Start and Output Discharge
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • High/Low Side Current Limit
  • Enable/Shutdown Function
  • Small SOT-23-5 package

General Description
The APW9109 is a 3A synchronous buck converter that uses current-mode control scheme to convert wide input voltage of 2.9V to 5.5V to outputs as low as 0.3V while providing excellent output voltage regulation. The APW9109 is equipped with an automatic Skip/PWM mode operation. At light load, the IC operates in the Skip mode to reduce the switching losses. At heavy load, the IC works in PWM mode. The APW9109 is also equipped with Power-on-reset, internal soft-start and complete protections (under-voltage, over-voltage, over-temperature and current-limit) into a single low cost SOT-23-5 package. The IC also provides output capacitor discharge when it is disabled via the internal low side MOSFET.
檔案下載+ 加入洽詢+ 加入比較 +
APW9140
Active
3A, 24V, 800kHz Synchronous Buck Converter with Ultrasonic Mode

Features
  • Input Voltage Range: 4.5V to 24V
  • 3A Output Current
  • Low 55μA (typ.) Quiescent Current
  • Typical 0.6V ±1% Reference Voltage
  • Fixed 800kHz Switching Frequency
  • Excellent Light Load Efficiency by Pulse Skip Mode
  • Stable with Low ESR Ceramic Capacitors
  • 5ms Integrated Soft Start
  • Ultrasonic Mode (Fsw > 25kHz)
  • 100% Duty Cycle for USB PD Application
  • Built in OVP, UVP, Current Limit and OTP
  • Small TSOT-23-6A package

General Description
The APW9140 is a 3A synchronous buck converter with a current-mode control scheme that operates over a wide input voltage range of 4.5V to 24V and converts output voltages as low as 0.6V and as high as VIN with 100% duty cycle. The APW9140 is equipped with an automatic skip mode operation to have high efficiency at light load. The ultrasonic mode can keep switching frequency always higher than 25kHz at extra light load to prevent audible noise. Power-on-reset, 5ms internal soft start and complete protections including under-voltage, over-voltage, overtemperature and current-limit are implemented into a single low cost TSOT-23-6A package.
檔案下載+ 加入洽詢+ 加入比較 +
APW9169C
Active
1A, Synchronous Buck Converter

Features
  • Input Voltage Range: 2.7V to 5.5V
  • Typical 0.6V Internal Reference Voltage
  • 1A Output Current
  • Constant on Time Mode Operation
  • 2.4MHz Force PWM Mode Operation Frequency
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrated 0.5ms Soft Start Time and Output Discharge
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • Small TDFN1.0x1.5-6 Package

General Description
The APW9169C is a 1A synchronous buck converter that uses constant on time mode control scheme to convert wide input voltage of 2.7V to 5.5V to outputs as low as 0.6V while providing excellent output voltage regulation. The APW9169C is also equipped with Power-on-reset, internal soft start and complete protections (under-voltage, over temperature and current-limit) into a single low cost TDFN1.0x1.5-6 package. The IC also provides output capacitor discharge when it is disabled via the discharge MOSFET.
檔案下載+ 加入洽詢+ 加入比較 +
APW9170C
Active
2A, 5V Input, Synchronous Buck Converter

Features
  • Input Voltage Range: 2.7V to 5.5V
  • Typical 0.6V Internal Reference Voltage
  • 2A Output Current
  • Constant on Time Mode Operation
  • 2.5MHz Force PWM Mode Operation Frequency
  • Stable with Low ESR Ceramic Capacitors
  • Power-On-Reset Detection on VIN
  • Integrated 1ms Soft Start Time and Output Discharge
  • Over-Temperature Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • Power Good Indication
  • Small TDFN2x2-6A and TSOT23-6A Packages

General Description
The APW9170C is a 2A synchronous buck converter that uses constant on time mode control scheme to convert wide input voltage of 2.7V to 5.5V to outputs as low as 0.6V while providing excellent output voltage regulation. The APW9170C is also equipped with Power-on-reset, internal soft start and complete protections (under-voltage, over temperature and current-limit) into low cost TDFN2x2-6A and TSOT23-6A packages. The IC also provides output capacitor discharge when it is disabled via the discharge MOSFET.
檔案下載+ 加入洽詢+ 加入比較 +
APW9114
Active
Peak 5A, 18V, 500kHz Synchronous Step-Down Converter

Features
  • Input Voltage range: 4.5V to 18V
  • Peak 5A Output Current, continue 4.3A
  • Typical 0.6V ±1% Internal Reference Voltage
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (65mΩ) for High Side
- N-CH MOSFET (35mΩ) for Low Side
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TSOT-23-8 package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW9114 is a high efficiency synchronous buck converter with integrated 65mΩ/35mΩ of upper/lower power MOSFET and offers 4.3A continuous current capability. The APW9114 uses a peak current mode control scheme to regulate the output voltage. The internal switching frequency is set at 500kHz. The APW9114 is also equipped with Power-on-reset, soft-start, and whole protections (over-temperature, overvoltage, under-voltage, over-current) into a single package. The APW9114 is offered in a TSOT-23-8 package allowing small size while having an excellent thermal capability for power dissipation.
檔案下載+ 加入洽詢+ 加入比較 +
APW9202/S/L
Active
3A, 18V, 600kHz Synchronous Step-Down Converter

Features
  • Input Voltage range: 4.5V to 18V
  • 3A/2A Output Current on Channel1/2
  • Low IQ=155μA (typ.) to improve Light Load Efficiency
  • Typical 0.6V ±1% Internal Reference Voltage
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (95mΩ) for CH1 High Side
- N-CH MOSFET (50mΩ) for CH1 Low Side
- N-CH MOSFET (105mΩ) for CH2 High Side
- N-CH MOSFET (60mΩ) for CH2 Low Side
  • Channel Swap Function (APW9202S)
  • Level Shifter Output is Referenced to External DC Voltage (APW9202L)
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost VTQFN2x2-13 package
  • Lead Free and Green Devices Available (RoHS Compliant)
  • DyncBandwidthTM Technology

General Description
The APW9202/S/L is a two-channel synchronous mode PWM converter with 3A continuous current capability for one channel and 2A continuous current capability for the other one. Each channel of the APW9202/S has independent enable, and it also allows the two regulators to start together by using the same enable signal. Although the switching frequency of the APW9202/S/L is fixed at 800kHz, it can also change the switching frequency via the PWM/SYNC pin. Another feature of this part is its ability to automatically optimize its BW (DyncBandwidth) to allow better dynamic response once it is synchronized to a higher external clock. The APW9202/S/L also provides a 180-degree phase shifting technique to minimize switching noise. The output voltage of each channel can be adjusted using an external resistor divider. Other features include UVP, current limit, and OTP. The APW9202/S/L is available in a VTQFN2x2-13 package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +
APW9202M
Active
High Efficiency 18V, 2-CH Buck Converter

Features
  • Input Voltage range: 4.5V to 18V
  • 3A/2A Output Current on Channel 1/2
  • Low IQ=155μA (typ.) to improve Light Load Efficiency
  • Typical 0.6V ±1% Internal Reference Voltage
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (95mΩ) for CH1 High Side
- N-CH MOSFET (50mΩ) for CH1 Low Side
- N-CH MOSFET (105mΩ) for CH2 High Side
- N-CH MOSFET (60mΩ) for CH2 Low Side
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost VTQFN2x2-13 package
  • DyncBandwidthTM Technology

General Description
The APW9202M is a two-channel synchronous mode PWM converter with 3A continuous current capability for one channel and 2A continuous current capability for the other one. Each channel of the APW9202M has independent enable, and it also allows the two regulators to start together by using the same enable signal. Although the switching frequency of the APW9202M is fixed at 800kHz, it can also change the switching frequency via the PWM/SYNC pin. Another feature of this part is its ability to automatically optimize its BW (DyncBandwidth) to allow better dynamic response once it is synchronized to a higher external clock. The APW9202M also provides a 180-degree phase shifting technique to minimize switching noise. The output voltage of each channel can be adjusted using an external resistor divider. Other features include UVP, current limit, and OTP. The APW9202M is available in a VTQFN2x2-13 package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +
APW9208
Active
Dual 2.4MHz, 6A/2A Synchronous Buck Converter

Features
  • Input Voltage range: 2.5V to 5.5V
  • 6A/2A Output Current on Channel 1/2
  • Typical 0.6V ±1% Internal Reference Voltage
  • 2.4MHz Constant Frequency Operation
  • Current Mode Operation
  • Internally Compensated
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost VTQFN3x2-18 package
  • Lead Free and Green Devices Available (RoHS Compliant)
  • Force PWM Mode Operation
  • DyncBandwidthTM Technology
  • SpeedTransTM Technology (Channel 1 only)
  • PowerGood Monitoring (Channel 1 only)

General Description
The APW9208 is a two-channel synchronous mode PWM converter with 6A continuous current capability for one channel and 2A continuous current capability for the other one. Another feature of this part is its ability to automatically optimize its BW (DyncBandwidth) to allow better dynamic response once it is synchronized to a higher external clock. The converter synchronizes its switching frequency to two times the frequency on the EN/SYNC pin. The APW9208 uses a peak current mode control scheme to regulate the output voltage. The internal switching frequency is set at 2.4MHz. While the EN/SYNC pin supports external clock synchronization. DyncBandwidthTM improves transient response when receiving higher external Synchronization clock. The APW9208 also equips a technique: SpeedTransTM which allows improving transient response without co plex external compensation circuits design. The APW9208 is also equipped with Power-on-reset, soft-start, and complete protections, over-temperature, over-voltage, under-voltage and over-current of the converter. The APW9208 is offered in a VTQFN3x2-18 package allowing small size while having an excellent thermal capability for power dissipation.
檔案下載+ 加入洽詢+ 加入比較 +
APW9209
Active
Dual 2.4MHz, 8A/2A Synchronous Buck Converter

Features
  • Input Voltage range: 2.5V to 5.5V
  • 8A/2A Output Current on Channel 1/2
  • Typical 0.6V ±1% Internal Reference Voltage
  • 2.4MHz Constant Frequency Operation
  • Current Mode Operation
  • Internally Compensated
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost VTQFN3x2-18 package
  • Lead Free and Green Devices Available (RoHS Compliant)
  • Force PWM Mode Operation
  • DyncBandwidthTM Technology
  • SpeedTransTM Technology (Channel 1 only)
  • PowerGood Monitoring (Channel 1 only)

General Description
The APW9209 is a two-channel synchronous mode PWM converter with 8A continuous current capability for one channel and 2A continuous current capability for the other one. Another feature of this part is its ability to automatically optimize its BW (DyncBandwidth) to allow better dynamic response once it is synchronized to a higher external clock. The converter synchronizes its switching frequency to two times the frequency on the EN/SYNC pin. The APW9209 uses a peak current mode control scheme to regulate the output voltage. The internal switching frequency is set at 2.4MHz. While the EN/SYNC pin supports external clock synchronization. DyncBandwidthTM improves transient response when receiving higher external Synchronization clock. The APW9209 also equips a technique: SpeedTransTM which allows improving transient response without complex external compensation circuits design. The APW9209 is also equipped with Power-on-reset, soft-start, and complete protections, over-temperature, over-voltage, under-voltage and over-current of the converter. The APW9209 is offered in a VTQFN3x2-18 package allowing small size while having an excellent thermal capability for power dissipation.
檔案下載+ 加入洽詢+ 加入比較 +
APW9211S
Active
High Efficiency 16V, 2-CH Buck Converter

Features
  • Input Voltage range: 4.5V to 16V
  • 4A/2A Output Current on Channel 1/2
  • Low IQ=155μA (typ.) to improve Light Load Efficiency
  • Typical 0.6V ±1% Internal Reference Voltage
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (75mΩ) for CH1 High Side
- N-CH MOSFET (45mΩ) for CH1 Low Side
- N-CH MOSFET (95mΩ) for CH2 High Side
- N-CH MOSFET (55mΩ) for CH2 Low Side
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost VTQFN2x2-13 package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW9211S is a two-channel synchronous mode PWM converter with 4A continuous current capability for one channel and 2A continuous current capability for the other one. Each channel of the APW9211S has independent enable, and it also allows the two regulators to start together by using the same enable signal and the same soft-start capacitor. Although the switching frequency of the APW9211S is fixed at 600kHz. The APW9211S also provides a 180-degree phase shifting technique to minimize switching noise. The output voltage of each channel can be adjusted using an external resistor divider. Other features include UVP, current limit, and OTP. The APW9211S is available in a VTQFN2x2-13 package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +
APW9213
Active
Dual 2.4MHz, 4A/2A Synchronous Buck Converter

Features
  • Input Voltage range: 2.5V to 5.5V
  • 4A/2A Output Current on Channel 1/2
  • Typical 0.6V ±1% Internal Reference Voltage
  • 2.4MHz Constant Frequency Operation
  • Current Mode Operation
  • Internally Compensated
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost VTQFN3x2-18 package
  • Lead Free and Green Devices Available (RoHS Compliant)
  • Force PWM Mode Operation
  • DyncBandwidthTM Technology

General Description
The APW9213 is a two-channel synchronous mode PWM converter with 4A continuous current capability for one channel and 2A continuous current capability for the other one. Another feature of this part is its ability to automatically optimize its BW (DyncBandwidth) to allow better dynamic response once it is synchronized to a higher external clock. The converter synchronizes its switching frequency to two times the frequency on the EN/SYNC pin. The APW9213 uses a peak current mode control scheme to regulate the output voltage. The internal switching frequency is set at 2.4MHz. While the EN/SYNC pin supports external clock synchronization. DyncBandwidthTM improves transient response when receiving higher external Synchronization clock. The APW9213 is offered in a VTQFN3x2-18 package allowing small size while having an excellent thermal capability for power dissipation.
檔案下載+ 加入洽詢+ 加入比較 +
APW9399
Active
3-CH Buck Converter, 4.5-24V Input Voltage, Tiny Package

Features
  • Wide Input Voltage from 4.5V to 24V
  • 2.5A/1.5A/1.5A Output Current on Channel 1/2/3
  • Low IQ=160uA (typ.) per channel supply to improve Light Load Efficiency at Sync off
  • Typical 0.6V ±1% Internal Reference Voltage
  • Sync Pin Allows Synchronization to an External
  • Clock from 500kHz to 2MHz
  • Optimized Upper and Lower MOSFETs RDS_on for max Efficiency:
- N-CH MOSFET (120mΩ) for CH1/2/3 High Side
- N-CH MOSFET (30mΩ) for CH1 Low Side
- N-CH MOSFET (50mΩ) for CH2/3 Low Side
  • Built in OVP, UVP, Current Limit and OTP
  • Low Cost TQFN3x3-20A package
  • Lead Free and Green Devices Available (RoHS Compliant)

General Description
The APW9399 is a three-channel synchronous mode PWM converter with 2.5A continuous current capability for one channel and 1.5A continuous current capability for the other two channels. Although the switching frequency of the APW9399 is fixed at 600kHz, it can also change the switching frequency via the SYNC pin. The APW9399 also provides a 120-degree phase shifting technique. To minimize switching noise. The output voltage of each channel can be adjusted using an external resistor divider. Other features include OVP, UVP, current limit, and OTP. The APW9399 is available in a TQFN3x3-20A package with small size and excellent thermal capacity.
檔案下載+ 加入洽詢+ 加入比較 +

洽詢車

你的洽詢車總計 0 件產品

    產品比較

    你的比較總計0件產品

      偵測到您已關閉Cookie,為提供最佳體驗,建議您使用Cookie瀏覽本網站以便使用本站各項功能

      依據歐盟施行的個人資料保護法,我們致力於保護您的個人資料並提供您對個人資料的掌握。 我們已更新並將定期更新我們的隱私權政策,以遵循該個人資料保護法。請您參照我們最新版的 隱私權聲明
      本網站使用cookies以提供更好的瀏覽體驗。如需了解更多關於本網站如何使用cookies 請按 這裏
